- Diameter of connector: Inner 2.1mm Nut; Outside: 5,5mm Mom. Material: plastic, copper. Voltage: 0-24V. Current: 2A.
- Color: Black. For 5V-24V power adapter extension cable. It can be used plug DC adapter for CCTV surveillance camera and LED strip etc.
- For DC power - Recommended up to 24 volt, max load 2amp or less. For any applications that requires DC input and accept 2.1mm x 5.5mm plug (Does not work with other size)
SKU Number DC_1F1M-16.4 DC Jack inside diameter 2.1mm DC Jack outside diameter 5.5mm Cable length 16.4 Ft (5M ) -
Visit product page →Flexible connector for 5050 LED strips. Helps to connect pieces of LED strips when cut.
SKU Number STRIP-FL-CON Types of LED Strips SMD 5050, RGB Cable Length 5.91 in (15 cm) Min LED Strip length 0.39 in (10 mm) -
Visit product page →LED Lights 3 way DC Splitter Cable Connects 3 LED lights or strips to 1 power supply. Great for Under cabinet Lights, LED strips, CCTV cameras. Easy to use. No soldering required. 1 Female to 3 Males.
SKU Number DC_1F3M DC Jack inside diameter 2.1mm DC Jack outside diameter 5.5mm Cable length 14.57 in (37 cm) -
Visit product page →LED Lights 2 way DC Splitter Cable Connects 2 LED lights or strips to 1 power supply. Great for Under cabinet Lights, LED strips, CCTV cameras. Easy to use. No soldering required. 1 Female to 3 Males.
SKU Number DC_1F2M DC Jack inside diameter 2.1mm DC Jack outside diameter 5.5mm Cable length 14.57 in (37 cm) -
Visit product page →DC Connectors for LED strips and Under Cabinet Lights (Male).
DC Jack diameter: 5.5mm (outside), 2.1mm (inside)SKU Number STRIP-CON-M Types of LED Strips, Under Cabinet lights SMD 5050, 3528; CAB-3W-XXD12V Min LED Strip length 0.39 in (10 mm) -
Visit product page →96W Integrated LED Driver Full-Range Dimmer & Color Temperature Controller
The Luxrite LR36141 is a compact all-in-one LED power and control solution, combining a high-efficiency Class 2 driver, full-range dimmer, and CCT (correlated color temperature) slider into a single unit. Designed for seamless integration into residential and commercial lighting systems, this micro driver delivers smooth dimming, flexible color tuning, and flicker-free 24VDC output.
- Supports 2700K-5000K
- Ultra-smooth 0–100% dimming with 4096 levels
- Fine-tuned control via touch-sensitive remote color wheel
- Linear dual-color tuning with no flicker
- 2.4GHz signal range up to 30 meters (barrier-free)Â
- Match up to 10 remotes per controller
- Auto-transmitting and synchronization between multiple controllers
- Works with 12–24VDC constant voltage LED tape lights
- Dual channel output: up to 120W per channel at 24V
- Power-off memory saves last light state
- Optional fade-in/fade-out on power on/off
- Power-off memory saves last light state
- Two pairing methods: button match or power cycling
- Compact, low-profile design with mounting rack included
Â
Spec Sheet
Spec Sheet
Installation Instructions
Info
Wattage 96W Input Voltage 120VAC, 60Hz Output Voltage 24VDC (adjustable to 26V) Output Current 4A Efficiency 91% @ full load Dimming Range 0.3% – 100% Certifications UL/cUL, FCC, RoHS, SELV Environment Dry/damp location, -40°F to 140°F Protection Short-circuit, overload, overheat Warranty 5 Years Accessories
-
Visit product page →160W Integrated LED Driver Full-Range Dimmer & Color Temperature Controller
The Luxrite LR36143 is a compact all-in-one LED power and control solution, combining a high-efficiency Class 2 driver, full-range dimmer, and CCT (correlated color temperature) slider into a single unit. Designed for seamless integration into residential and commercial lighting systems, this micro driver delivers smooth dimming, flexible color tuning, and flicker-free 24VDC output.
- Supports 2700K-5000K
- Ultra-smooth 0–100% dimming with 4096 levels
- Fine-tuned control via touch-sensitive remote color wheel
- Linear dual-color tuning with no flicker
- 2.4GHz signal range up to 30 meters (barrier-free)Â
- Match up to 10 remotes per controller
- Auto-transmitting and synchronization between multiple controllers
- Works with 12–24VDC constant voltage LED tape lights
- Dual channel output: up to 120W per channel at 24V
- Power-off memory saves last light state
- Optional fade-in/fade-out on power on/off
- Power-off memory saves last light state
- Two pairing methods: button match or power cycling
- Compact, low-profile design with mounting rack included
Â
Spec Sheet
Spec Sheet
Installation Instructions
Info
Wattage 160 Input Voltage 120VAC, 60Hz Output Voltage 24VDC (adjustable to 26V) Output Current 6.67A Efficiency 94.5% @ full load Dimming Range 0.3% – 100% Certifications UL/cUL, FCC, RoHS, SELV Environment Dry/damp location, -40°F to 140°F Protection Short-circuit, overload, overheat Dimensions 4.13" x 2.13" x 2.00" Warranty 5 Years Accessories
-
Visit product page →LED Lights 4 way DC Splitter Cable Connects 4 LED lights or strips to 1 power supply. Great for Under cabinet Lights, LED strips, CCTV cameras. Easy to use. No soldering required. 1 Female to 3 Males.
SKU Number DC_1F4M DC Jack inside diameter 2.1mm DC Jack outside diameter 5.5mm Cable length 14.57 in (37 cm) -
Visit product page →DC Connectors for LED strips and Under Cabinet Lights (Female).
DC Jack diameter: 5.5mm (outside), 2.1mm (inside)SKU Number STRIP-CON-F Types of LED Strips SMD 5050, 3528 Min LED Strip length 0.39 in (10 mm) -
LEDQuant
LED strip connector adapter for flexible smd 5050 3528 led single color strips light
4.99 $3.99
vLEDQuant
LED strip connector adapter for flexible smd 5050 3528 led single color strips light
$4.99 $3.99
Visit product page →Flexible connector for 5050 & 3528 Single Color LED strips. Helps to connect pieces of LED strips when cut.
SKU Number STRIP-CON-SC Types of LED Strips SMD 5050, 3528 Single Color Cable Length 6.69 in (170mm) Connector width 0.43 in (11 mm)
