Commercial Outdoor Lights

50 Watt LED Outdoor Flood Light, Cool White, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.

10 Watt Outdoor LED Flood Light, RGB, Color Changing, Energy Efficient. Reduced energy consumption by up to 80%. Remote Control & Power supply included, 2 year guarantee.

The CLMAL series is a group of premium architectural LED multi-purpose area luminaires designed to illuminate parking lots, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.

 FEATURES

▪ Available in 3000k (warm white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
▪ Long-life LEDs provide 372,000 hours of operation with at least 70% of initial lumen output (L70).**
▪ CLMAL-15 provides 1,593 lumens (114 lumens per watt, LPW) at 3000k; 1,603 lumens (115 LPW) at 4000k; and 1,624 lumens (116 LPW) at 5000k.*
▪ Standard optic provides an IES roadway type V distribution, or a 7V (vertical) x 7H (horizontal) NEMA floodlight distribution.
▪ Universal 120-277 AC voltage (50-60Hz) is standard.
▪ Power factor > 0.90.
▪ Total harmonic distortion < 20%.
▪ Color rendering index > 80.
▪ Optional glare shields (full & half) & wire guards are available.
▪ Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heat-resistant polycarbonate lens.
▪ Wireway enclosure is sealed with a water-tight, silicon rubber gasket.
▪ Effective projected areas (EPA's) are:
- Front = 0.05 s.f. (knuckle) / 0.06 s.f. (yoke)
- Side = 0.07 s.f. (knuckle & yoke)
- Face = 0.20 s.f. (knuckle) / 0.23 s.f. (yoke)
▪ Easy installation in new construction or retrofit applications.


* contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS

• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F).
• IP66 rated for ingress protection.
• DLC premium approved.
• Rated for 3G vibration.
• Lens is IK 8 rated for protection from external impacts.
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test.
• Complies with FCC Part 15, class B.
• Complies with EN61000-4-5, surge immunity protection (2.5kV).
• 5-Year Warranty of all electronics and housing.

 MOUNTING OPTIONS

• Yoke-mounted option provides secure attachment to flat surfaces.
• Aluminum die-cast knuckle-mount option is installed on a junction box. Includes ½” NPS stem with locking nut.

Specification Sheet

Selectable LED Architectural Wall Pack Lighting series can be widely used in indoor or outdoor lighting (wet location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

12Vdc Auxiliary Dimming

Power: 48W / 72W / 96W / 120W
Input: AC 120-277V
CCT: 4000K / 5000K
Output: 7800 LM/11288 LM/14627 LM/18550 LM
Type of lighting： T3 / T4 / T5

Factory Default Parameters:
Power: 120W
CCT：4000K
Type of lighting: T4
Driver: KERHAM

Selectable LED Architectural Wall Pack Lighting series can be widely used in indoor or outdoor lighting (wet location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

**12Vdc Auxiliary Dimming**

Power: 28W / 42W / 56W / 70W
Input: AC 120-277V
CCT: 3000K / 4000K / 5000K
Output: 4760 LM/6880 LM/8601 LM/11124 LM
Type of lighting： T3 / T4 / T5

Factory Default Parameters:
Power: 70W
CCT：4000K
Type of lighting: T4
Driver: KERHAM

Selectable LED Architectural Wall Pack Lighting series can be widely used in indoor or outdoor lighting (wet location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

12Vdc Auxiliary Dimming

Power: 28W / 42W / 56W / 70W
Input: AC 120-277V
CCT: 3000K / 4000K / 5000K
Output: 4760 LM/6880 LM/8601 LM/11124 LM
Type of lighting： T3 / T4 / T5

Factory Default Parameters: Item:
Power: 70W
CCT：4000K
Type of lighting: T4
Driver: KERHAM

LED Mini Wall Pack Light series can be widely used as indoor or outdoor lighting (Wet location). Excellent for mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station, and indoor stadiums.

Power: 15W
Input: AC 120-277V
CCT：3000K/4000K/5000K
Output: 2130 Lm / 2218 Lm / 2246 Lm
Light Source: Lumileds
Driver: KERHAM POWER

Factory Default Parameters:
Power: 15W
CCT： 4000K

LED Mini Wall Pack Light series can be widely used as indoor or outdoor lighting (Wet location). Excellent for mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station, and indoor stadiums.


Power: 10W
Input: AC 120-277V
CCT：5000K
Output: 1450 Lm
Light Source: Lumileds
Driver: KERHAM POWER

Selectable LED GLASS WALL PACK LED Lighting Series can be widely used for indoor or outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.


Power: 28W / 42W / 56W / 70W
Input: AC 120-277V
CCT: 3000K /4000K / 5000K
Output: 4800 LM/6393 LM/7880 LM/9808 LM

Factory Default Parameters:
Power: 70W
CCT: 4000K
Light Source: 2835 LEDs
Driver: KERHAM

LED GLASS WALL PACK Lighting series can be widely used as indoor or outdoor lighting (Wet location). Perfect for mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station, indoor stadiums and flower cultivating tents, etc.


Power: 50W
Input: AC 120-277V
CCT：5000K
Output: 6600 LM
Light Source: Lumileds
Driver: WELED POWER

The Selectable Full Cutoff Wall Pack LED Lighting Series can be widely used for indoor or outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

Power: 28W / 42W / 56W / 70W
Input: AC 120-277V
CCT: 3000K /4000K / 5000K
Output: 4116 LM/6174 LM/7840 LM/9800 LM

Factory Default Parameters:
Power: 70W
CCT：4000K
Light Source: 2835 LEDs
Driver: KERHAM

The Architectural WALL PACK LED Lighting Series can be widely used for indoor or outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications


Power: 70W
Input: AC 120-277V
CCT：5000K
Output: 9841 LM
Light Source: Lumileds

Selectable LED Slim Adjustable Wall Pack series can be widely used in indoor or outdoor lighting (wet location). The head tilts from 0º to 90º. Ideal for mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station, indoor stadiums.

** Photocell control available (Standard)**
** 1-10V Dimming**

Power: 40W / 60W / 80W
Input: AC 120-277V
CCT: 3000K/4000K/5000K
Output: 10000LM/11200LM/10800LM
Light Source: Lumileds
Driver: Daermay

Factory Default Parameters:
Power:80W
CCT：4000K

Selectable LED Slim Adjustable Wall Pack series can be widely used in indoor or outdoor lighting (wet location). The head tilts from 0º to 90º. Ideal for mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station, indoor stadiums.

** Photocell control available (Standard)**
** 1-10V Dimming**

Power: 15W / 20W / 30W
Input: AC 120-277V
CCT: 3000K/4000K/5000K
Output: 3750LM/4200LM/4050LM
Light Source: Lumileds
Driver: HBE

Factory Default Parameters:
Power:30W
CCT：4000K

Adjustable WALL PACK LED Lighting Series can be widely used for indoor or outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.


Power: 70W
Input: AC 120-277V
CCT: 5000K
Output: 9170 Lm
Light Source: Lumileds
Driver: KERHAM

Selectable LED Architectural Wall Pack Lighting series can be widely used in indoor or outdoor lighting (wet location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

12Vdc Auxiliary Dimming

Power: 48W / 72W / 96W / 120W
Input: AC 277-480V
CCT: 4000K / 5000K
Output: 7800 LM/11288 LM/14627 LM/18550 LM
Type of lighting： T3 / T4 / T5

Factory Default Parameters:
Power: 120W
CCT：4000K
Type of lighting: T4
Driver: KERHAM

Selectable LED Architectural Wall Pack Lighting series can be widely used in indoor or outdoor lighting (wet location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

**12Vdc Auxiliary Dimming**


Power: 28W / 42W / 56W / 70W
Input: AC 277- 480V
CCT: 3000K / 4000K / 5000K
Output: 4760 LM/6880 LM/8601 LM/11124 LM
Type of lighting： T3 / T4 / T5

Factory Default Parameters:
Power: 70W
CCT：4000K
Type of lighting: T4
Driver: KERHAM

Selectable LED Architectural Wall Pack series can be widely used in indoor or outdoor lighting (wet location). Ideal for museums, art galleries, shopping malls, office buildings, walls and many other applications.

Power: 12W / 18W / 24W / 30W
Input: AC 120-277V
CCT: 3000K / 4000K / 5000K
Output: 12W 1608 LM / 1704 LM / 1680 LM
             18W 2340 LM / 2520 LM / 2448 LM
             24W 3024 LM / 3264 LM / 3120 LM
             30W 3630 LM / 3960 LM / 3750 LM

Factory Default Parameters:
Power: 30W
CCT：4000K
Driver: KERHAM

The Selectable Semi-Cutoff Wall Pack LED Lighting Series can be widely used for Indoor or Outdoor (Wet Location) Excellent for Museums, Art Galleries, Shopping Malls, Office Buildings, Walls and many other applications.

Power: 48W / 76W / 92W / 120W
Input: AC 120-277V
CCT: 4000K / 5000K
Output: 7496LM / 10985 LM
            14162 LM / 17226 LM

Factory Default Parameters:
Power: 120W
CCT: 4000K
Light Source: 2835 LEDs
Driver: KERHAM

The Selectable Semi-Cutoff Wall Pack LED Lighting Series can be widely used for Indoor or Outdoor (Wet Location) Excellent for Museums, Art Galleries, Shopping Malls, Office Buildings, Walls and many other applications.

Power: 28W / 42W / 56W / 70W
Input: AC 120-277V
CCT: 3000K/ 4000K / 5000K
Output:  4483 LM / 5896  LM
               7740 LM / 9753 LM

Factory Default Parameters:
Power: 70W
CCT: 4000K
Light Source: 2835 LEDs
Driver: KERHAM
