10 Watt Outdoor LED Flood Light, RGB, Color Changing, Energy Efficient. Reduced energy consumption by up to 80%. Remote Control & Power supply included, 2 year guarantee.

10 Watt Outdoor LED Flood Light, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.

The CLMAL series is a group of premium architectural LED multi-purpose area luminaires designed to illuminate parking lots, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.

 FEATURES

▪ Available in 3000k (warm white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
▪ Long-life LEDs provide 372,000 hours of operation with at least 70% of initial lumen output (L70).**
▪ CLMAL-15 provides 1,593 lumens (114 lumens per watt, LPW) at 3000k; 1,603 lumens (115 LPW) at 4000k; and 1,624 lumens (116 LPW) at 5000k.*
▪ Standard optic provides an IES roadway type V distribution, or a 7V (vertical) x 7H (horizontal) NEMA floodlight distribution.
▪ Universal 120-277 AC voltage (50-60Hz) is standard.
▪ Power factor > 0.90.
▪ Total harmonic distortion < 20%.
▪ Color rendering index > 80.
▪ Optional glare shields (full & half) & wire guards are available.
▪ Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heat-resistant polycarbonate lens.
▪ Wireway enclosure is sealed with a water-tight, silicon rubber gasket.
▪ Effective projected areas (EPA's) are:
- Front = 0.05 s.f. (knuckle) / 0.06 s.f. (yoke)
- Side = 0.07 s.f. (knuckle & yoke)
- Face = 0.20 s.f. (knuckle) / 0.23 s.f. (yoke)
▪ Easy installation in new construction or retrofit applications.


* contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS

• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F).
• IP66 rated for ingress protection.
• DLC premium approved.
• Rated for 3G vibration.
• Lens is IK 8 rated for protection from external impacts.
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test.
• Complies with FCC Part 15, class B.
• Complies with EN61000-4-5, surge immunity protection (2.5kV).
• 5-Year Warranty of all electronics and housing.

 MOUNTING OPTIONS

• Yoke-mounted option provides secure attachment to flat surfaces.
• Aluminum die-cast knuckle-mount option is installed on a junction box. Includes ½” NPS stem with locking nut.

Specification Sheet

20 Watt LED Outdoor Flood Light, Cool White, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.

Features

• Finish: Bronze, White
• Wattage: 30W
• Lumens: 2800
• Color Temperature: 3000K
• Voltage: 120V
• CRI: 80
• Light Beam Angle: 120°
• Westgate's versatile Dimmable Flood Lights with motion sensor and photocell options
• Can be installed with any standard LED dimmers (TRIAC types)
• Mounts flush on wall or 4 round weatherproof box
• Housing: Die-cast aluminum with powder coat finish
• Cover type: clear lens
• Ideal for doorway, pathway and alleys

Documents

• Spec Sheet

Labels:

Looking to mount your 2 3/8 inch area flood light or cobra head light to a round light pole here is the adapter to make that happen.

Designed with safety as a top priority, this twin head, fully hooded security light is constructed of long lasting steel with finishes available in powder coated black, matte white or powder coated bronze. The swiveling twin heads allow for easy directional lighting and the PAR38 recommended bulb is ideal for distance lighting without the glare. Light bulb not included.

The CLMAL series is a group of premium architectural multi-purpose LED area luminaires designed to illuminate parking areas, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.

 FEATURES

▪ Available in 3000k (warm white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
▪ Long-life LEDs provide 372,000 hours of operation with at least 70% of initial lumen output (L70).**
▪ CLMAL-30 provides 3,404 lumens (113 lumens per watt, LPW) at 3000k; 3,427 lumens (114 LPW) at 4000k; and 3,432 lumens (114 LPW) at 5000k.*
▪ Standard optic provides an IES roadway type V distribution, or a 7V (vertical) x 7H (horizontal) NEMA floodlight distribution.
▪ Universal 120-277 AC voltage (50-60Hz) is standard.
▪ Power factor > 0.90.
▪ Total harmonic distortion < 20%.
▪ Color rendering index > 80.
▪ Optional glare shields (full & half) & wire guards are available.
▪ Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heat resistant polycarbonate lens.
▪ Wireway enclosure is sealed with a water-tight, silicon rubber gasket.
▪ Effective projected areas (EPA's) are:
- Front = 0.12 s.f. (knuckle) / 0.10 s.f. (yoke)
- Side = 0.15 s.f. (knuckle) / 0.09 s.f. (yoke)
- Face = 0.55 s.f. (knuckle) / 0.42 s.f. (yoke)
▪ Easy installation in new construction or retrofit applications.

* contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS

• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F).
• IP66 rated for ingress protection.
• DLC premium approved.
• Rated for 3G vibration.
• Lens is IK 8 rated for protection from external impacts.
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test.
• Complies with FCC Part 15, class B.
• Complies with EN61000-4-5, surge immunity protection (2.5kV).
• 5-Year Warranty of all electronics and housing.

 MOUNTING OPTIONS

• Yoke-mounted option provides secure attachment to flat surfaces.
• Aluminum die-cast knuckle-mount option is installed on a junction box. Includes ½” NPS stem with locking nut.

Specification Sheet

Bold and stylish, this twin head LED flood light system is constructed of heavy duty aluminum and available in either powder coated black or matte white. The LED lights provide wide angle reach and generate 1400 lumens with a 3000k crisp white light, brightly illuminating even the darkest outdoor areas.

The perfect solution for all your exterior security needs, the adjustable Twin Head Basic Floodlight with motion sensor is constructed of long-lasting aluminum and can be easily directed where needed. These sturdy fixtures are available in powder coat black, matte white, or powder coat bronze. Whether mounted on the wall or under an eave, they provide intense and focused illumination ideal for lighting up any exterior area.

Details:

Product Type: Spot Lights
Finish: Powder Coated Bronze
Shade: Clear

Measurements:

Width / Dia: 10.50"
Height: 4.25"
Length: 5.50"
Wire: 7.87"
Weight: 1.20lbs.

Lamping:

Bulb Qty: 2, Not Included
Max Wattage: 20.00W
Bulb Type: LED
Light Source: LED
Light Output: 1400.00
CCT: 3000K
CRI: 80
Dimmable: Yes
Rated Avg Life: 50000
Voltage: 120V

Addl Specifications:

Safety Listing: UL, ETL
Safety Rating: Wet

The perfect solution for all your exterior security needs, the adjustable Twin Head Basic Floodlight with motion sensor is constructed of long-lasting aluminum and can be easily directed where needed. These sturdy fixtures are available in powder coat black, matte white, or powder coat bronze. Whether mounted on the wall or under an eave, they provide intense and focused illumination ideal for lighting up any exterior area.

Details:

Product Type: Spot Lights
Finish: Powder Coated Black
Shade: Clear

Measurements:

Width / Dia: 11.25"
Height: 4.75"
Length: 6.00"
Wire: 7.87"
Weight: 1.16lbs.

Lamping:

Bulb Qty: 2, Not Included
Max Wattage: 25.00W
Bulb Type: Par 38
Bulb Base: E26 Medium
Light Source: Incandescent
Dimmable: Yes
Voltage: 120V

Addl Specifications:

Safety Listing: UL, ETL
Safety Rating: Wet

The perfect solution for all your exterior security needs, the adjustable Twin Head Basic Floodlight with motion sensor is constructed of long-lasting aluminum and can be easily directed where needed. These sturdy fixtures are available in powder coat black, matte white, or powder coat bronze. Whether mounted on the wall or under an eave, they provide intense and focused illumination ideal for lighting up any exterior area.

Details:

Product Type: Spot Lights
Finish: Powder Coated Bronze
Shade: Clear

Measurements:

Width / Dia: 11.25"
Height: 4.75"
Length: 6.00"
Wire: 7.87"
Weight: 1.16lbs.

Lamping:

Bulb Qty: 2, Not Included
Max Wattage: 25.00W
Bulb Type: Par 38
Bulb Base: E26 Medium
Light Source: Incandescent
Dimmable: Yes
Voltage: 120V

Addl Specifications:

Safety Listing: UL, ETL
Safety Rating: Wet

50 Watt LED Outdoor Flood Light, Cool White, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.

The CLMAL series is a group of premium architectural multi-purpose LED area luminaires designed to illuminate parking areas, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.

 FEATURES

• Available in 3000k (warm white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 230,000 hours of operation with at least 70% of initial lumen output (L70).**
• CLMAL-50 provides 5,717 lumens (117 lumens per watt, LPW) at 3000k; 5,778 lumens (118 LPW) at 4000k; and 5,793
lumens (118 LPW) at 5000k.*
• Standard optic provides an IES roadway type V distribution, or a 7V (vertical) x 7H (horizontal) NEMA floodlight distribution.
• Universal 120-277 AC voltage (50-60Hz) is standard.
• Power factor > 0.90.
• Total harmonic distortion < 20%.
• Color rendering index > 80.
• Optional glare shields (full & half) & wire guards are available.
• Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heat-resistant polycarbonate lens.
• Wireway enclosure is sealed with a water-tight, silicon rubber gasket.
• Effective projected areas (EPA’s) are:
- Front = 0.15 s.f. (knuckle) / 0.13 s.f. (yoke)
- Side = 0.18 s.f. (knuckle) / 0.13 s.f. (yoke)
- Face = 0.73 s.f. (knuckle) / 0.57 s.f. (yoke)
• Easy installation in new construction or retrofit applications.

* contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS

• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F).
• IP66 rated for ingress protection.
• DLC premium approved.
• Rated for 3G vibration.
• Lens is IK 8 rated for protection from external impacts.
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test.
• Complies with FCC Part 15, class B.
• Complies with EN61000-4-5, surge immunity protection (2kV).
• 5-year warranty of all electronics and housing

 MOUNTING OPTIONS

• Yoke-mounted option provides secure attachment to flat surfaces.
• Aluminum die-cast knuckle-mount option is installed on a junction box. Includes ½” NPS stem with locking nut.

Specification Sheet

WSD LED Flood Lighting series can be widely used in indoor or outdoor lighting (wet location). Ideal for excellent for museums, art galleries, shopping malls, office buildings, the lawn, walls, and many more applications.

FEATURES

• Wattage: 30W

• CCT: 4000K or 5000K
• Lumens: 4350 LM
• CRI: 70
• Input voltage: 120-277V
• Finish: Dark Bronze
• Lumileds LED, high luminous efficiency and long working life.
• High efficiency LED Driver, the wide range input voltage AC120-277V.
• Optics design, greatly improve the light utilization and evenness.
• Photocell Control Available (Option)

• Die-cast aluminum cooling design, high quality and better cooling for LED Tj < 85℃.
• Warranty: 5 years

• Life Span 75,000 hours
• Listings: UL Listed, DLC Premium, ROHS, Wet Location

WSD LED Flood Lighting series can be widely used in indoor or outdoor lighting (wet location). Ideal for excellent for museums, art galleries, shopping malls, office buildings, the lawn, walls, and many more applications.

FEATURES

• Wattage: 45W

• CCT: 4000K or 5000K
• Lumens: 6750 LM
• CRI: 70
• Input voltage: 120-277V
• Finish: Dark Bronze
• Lumileds LED, high luminous efficiency and long working life.
• High efficiency LED Driver, the wide range input voltage AC120-277V.
• Optics design, greatly improve the light utilization and evenness.
• Photocell Control Available (Option)

• Die-cast aluminum cooling design, high quality and better cooling for LED Tj < 85℃.
• Warranty: 5 years

• Life Span 75,000 hours
• Listings: UL Listed, DLC Premium, ROHS, Wet Location

The shoebox LED parking lot light use best die-casting aluminum housing, anti-corrosion painting IP65 design. High-performance illumination that lasts 50,000 hours.

Providing dual directional lighting, and available in either powder coated black or matte white, the Twin Head LED Floodlight with motion sensor greatly enhances visibility and is the perfect solution for outdoor security lighting. The weather-resistant aluminum housing ensures long-lasting durability, and the 1400LM is double security experts' recommendation of at least 700LM and ensures reliable safety lighting for any exterior or outdoor space

Details:

Product Type: Spot Lights
Finish: Powder Coated Matte Black
Shade: Clear

Measurements:

Width / Dia: 4.25"
Height: 10.50"
Length: 5.25"
Wire: 7.87"
Weight: 1.40lbs.

Lamping:

Bulb Qty: 2, Not Included
Max Wattage: 20.00W
Bulb Type: LED
Light Source: LED
Light Output: 1400.00
CCT: 3000K
CRI: 80
Rated Avg Life: 25000
Voltage: 120V

Addl Specifications:

Safety Listing: UL, ETL
Safety Rating: Wet

LEDSION LED Retrofit lamp is designed to retrofit traditional MH or HPS light bulbs with a E39 Mogul base, which well fit well to traditional street light housing, flood light, wall pack or other outdoor housings. with 130lm/W efficiency, and hanging wires to help it not fall off the fixture, also there is heat dissipation holes around the base, make it always low temperature while working. ideal for replacing 60-100W traditional bulbs.

The LED Shoebox Light series can be used in outdoor lighting (wet location certified). Excellent for parking lots, buildings, courtyards, industrial areas, sidewalks, schools and many other applications.

FEATURES:

• Lumileds LED: High lumen efficiency and long working life
• High efficiency LED Driver
• Input voltage AC120-277V
• High quality die cast aluminum design for excellent heat dissipation
• Optics designed to improve the light utilization and evenness

The CLMAL series is a group of premium architectural multi-purpose LED area luminaires designed to illuminate parking areas, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.


 FEATURES
• Available in 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 372,000 hours of operation with at least 70% of initial lumen output (L70)**
• Available models provide from 9,816 to 18,408 lumens, and from 117 to 131 lumens per watt (LPW)*
• IES roadway photometric distributions include types II-V
• NEMA floodlight distributions include very narrow (3H x 3V), medium narrow (4H x 4V), medium wide (5H x 5V) & very wide (7H x 7V)
• Universal 120-277 AC voltage (50-60Hz) is standard
• Power factor > 0.90
• Total harmonic distortion < 20%
• Color rendering index > 80
• Optional glare shields (full & half) & wire guards are available
• Optional NEMA photocell installation kit provides watertight photocell attachment to driver enclosure clover
• Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heatresistant polycarbonate lens
• Driver enclosure is sealed with a water-tight, silicone rubber gasket
• Effective projected areas (EPA’s) are:
- Front = 0.24 square feet
- Side = 0.29 square feet
- Face = 1.10 square feet
• Easy installation in new construction or retrofit applications


* Contact factory for other color temperatures and lumen packages.
** L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS

• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F)
• IP66 rated for ingress protection
• DLC premium approved
• Flicker-free per IEEE1789-2015 (no observable adverse effects of flicker at 100% light output level)
• Lens is IK 9 rated for protection from external impacts
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test
• Complies with FCC Part 15, class B
• Complies with EN61000-4-5, surge immunity protection (6kV)
• 5-Year Warranty of all electronics and housing

Specification Sheet

Our Area Light/Shoebox Series is the best option to replace 100W to 1000W metal halide luminaires. The slim profile design delivers maximum efficiency. A wide range of lumen packages for any type of applications. With extensive selection of accessories, including photocell receptacles, motion sensor, mountings and finish colors. Ideal for commercial parking lots, car dealership, walk ways, street lighting, and places where much needed light.

FEATURES

• Wattage: 100W

• CCT: 4000K or 5000K
• Lumens: 13000 LM
• CRI: 70
• Input voltage: 120-277V
• Finish: Dark Bronze
• Distribution: Type 3
• LED high luminous efficiency and long working life.

• High efficiency LED Driver, the wide range input voltage AC 120-277V
• Die-cast aluminum cooling design, high quality and better cooling for LED Tj < 85℃.
• Excellent optics design, greatly improve the light utilization and evenness.
• Dimming: 0-10Vdc

• Warranty: 5 years

• Life Span 50,000 hours
• Listings: UL Listed, DLC Premium, Wet Location, ROHS

WSD LED Flood Lighting series can be widely used in indoor or outdoor lighting (wet location). Ideal for excellent for museums, art galleries, shopping malls, office buildings, the lawn, walls, and many more applications.

FEATURES

• Wattage: 100W

• CCT: 4000K or 5000K
• Lumens: 14500 LM
• CRI: 70
• Input voltage: 120-277V
• Finish: Dark Bronze
• Lumileds LED, high luminous efficiency and long working life.
• High efficiency LED Driver, the wide range input voltage AC120-277V.
• Optics design, greatly improve the light utilization and evenness.
• Die-cast aluminum cooling design, high quality and better cooling for LED Tj < 85℃.

• Warranty: 5 years

• Life Span 75,000 hours
• Listings: UL Listed, DLC Premium, ROHS, Wet Location

WSD LED Flood Lighting series can be widely used in indoor or outdoor lighting (wet location). Ideal for excellent for museums, art galleries, shopping malls, office buildings, the lawn, walls, and many more applications.

FEATURES

• Wattage: 150W

• CCT: 4000K or 5000K
• Lumens: 21750 LM
• CRI: 70
• Input voltage: 120-277V
• Finish: Dark Bronze
• Lumileds LED, high luminous efficiency and long working life.
• High efficiency LED Driver, the wide range input voltage AC120-277V.
• Optics design, greatly improve the light utilization and evenness.
• Die-cast aluminum cooling design, high quality and better cooling for LED Tj < 85℃.

• Warranty: 5 years

• Life Span 75,000 hours
• Listings: UL Listed, DLC Premium, ROHS, Wet Location

FEATURES:

• Wattage Selectable: 150W/100W/80W
• Voltage: 120-277V
• Lumens: 12000/13000/22500LM
• CCT Selectable: 3000K/4000K/5000K
• CRI: 80
• 50,000 hours lifetime
• 0-10V dimming
• Working Temperature: -20°C to 45°C
• Ratings: UL Listed, DLC Premium, IP65
• BUG: B3-U0-G3
• Warranty: 5 years warranty
• Low profile housing with enhanced thermal heat sink
• High brightness lumileds LED chips.

APPLICATIONS:

• Warehouses
• Stadiums
• Factories
• Parking Lots
• Supermarkets
• Shopping Malls
• Logistic Centers
• Auto dealerships

WareLight LED Street Light and Cobra Head series provides uncompromising optical performance and outstanding versatility for a wide variety of outdoor area and roadway applications.

This fixture features Lumileds LED' for high luminous efficiency and long working life. It has a high efficiency LED driver with an input voltage of  AC100-277V. The die cast aluminum design is high quality and provides better cooling for LED Tj < 85℃. The excellent optics design greatly improves the light utilization and evenness.

The LED Shoebox Light series can be used in outdoor lighting (wet location certified). Excellent for parking lots, buildings, courtyards, industrial areas, sidewalks, schools and many other applications.

FEATURES:

• Lumileds LED: High lumen efficiency and long working life
• High efficiency LED Driver
• Input voltage AC277-480V
• High quality die cast aluminum design for excellent heat dissipation
• Optics designed to improve the light utilization and evenness

FEATURES

• Voltage: 120-277V
• Wattage Selectable: 100W/150W/200W

• Lumens Selectable: 15600/22950/30000LM
• CCT Selectable: 3000K/4000K/5000K

• CRI: 80
• 0-10V dimming standard
• Optical design, greatly improved the light utilization and evenness
• Compatible with most Lutron and Leviton dimmers
• Life Span ＞50000 hours
• Ratings: UL Listed, DLC Premium, Wet Location
• Warranty: 5 year limited

The LED Shoebox Light series can be used in outdoor lighting (wet location certified). Excellent for parking lots, buildings, courtyards, industrial areas, sidewalks, schools and many other applications.

FEATURES:

• Lumileds LED: High lumen efficiency and long working life
• High efficiency LED Driver
• Input voltage AC120-277V
• High quality die cast aluminum design for excellent heat dissipation
• Optics designed to improve the light utilization and evenness

The Selectable LED Shoebox Lighting Series can be widely used for Outdoor Excellent for Parking Lots, Pedestrian Walkways, Roadways, Tennis Courts, Basketball Courts, Stadiums, Arenas, Schools, Residential Areas and many other applications.

FEATURES

• Wattage Selectable: 60W/90W/120W/150W

• CCT Selectable: 4000K / 5000K
• Lumens: 21021 LM
• CRI: 70
• Input voltage: 120-277V
• Finish: Dark Bronze
• Optical design, greatly improved the light utilization and evenness
• High efficiency LED Driver, voltage AC120-277V
• Cast Aluminum design, better cooling, light quality, LED Tj <85°C
• Photocell Control & Motion Sensor (Optional)
• 1-10V dimming (10%-100%) standard
• Warranty: 5 years

• Life Span 75,000 hours
• Listings: UL Listed, DLC Premium
• Compatible with most Lutron and Leviton dimmers
