Field selectable 3500k (warm/neutral white), 4000k (neutral
white), & 5000k (cool white) color temperatures.*
▪ Long-life LEDs provide 144,000 hours of operation with at
least 70% of initial lumen output (L70), and 44,000 hours with at
least 90% of initial lumen output (L90).**
▪ Selectable lumen outputs range from 2,700 to 4,000 nominal
lumens.*
▪ Uniform illumination with no visible LED pixilation.
▪ Universal 120-277 AC voltage (50-60Hz) is standard.
▪ 0-10vdc dimming drivers are standard.
▪ Power factor > 90.
▪ Total harmonic distortion < 20%.
▪ Color rendering index > 80.
▪ Aluminum frame and steel housing backplate.
▪ PMMA (polymethyl methacrylate) LED lenses for optimal light
distribution, efficiency and longevity.
▪ Easy installation in new construction or retrofit.
▪ Standard earthquake clips provide secure installation in grid
ceilings.
▪ Optional emergency drivers are available.
▪ Standard mounting options include recessed mounting in grid
ceilings, or suspended mounting using attached hanging
brackets. For mounting in plaster or other hard ceiling, see
Mounting Kits.
