10 Watt Outdoor LED Flood Light, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.
| Power Consumption | 10W |
| Traditional Equivalent | 50W |
| Luminous Flux (lm) | 800 Lm |
| LED Brand | Epistar |
| IP Rating | IP 65 |
| Material | Aluminum Alloy |
| Plug | No |
| Light Temperature | Warm White (3000-3200K) |
| Input Voltage | 85-265V AC |
| Beam angle | 120° |
| Lamp Color | Grey |
| Length | 4.4in (112.0mm) |
| Height |
3.31in (84mm) |
| Depth |
3.27in (83mm) |
50 Watt LED Outdoor Flood Light, Cool White, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.
| SKU Number | FL-50W-CW |
| Power Consumption | 50W |
| Traditional Equivalent | 200W |
| Luminous Flux (lm) | 5000 Lm |
| LED Brand | Bridgelux |
| IP Rating | IP 65 |
| Material | Aluminum Alloy |
| Plug | No |
| Color temperature | Cool White (5500-7000K) |
| Input Voltage | 85-265V AC |
| Certificates | CE, RoHS |
| Warranty | 2 years |
| Life Span | 50000 hours |
| Length |
11.18in (284mm) |
| Height |
8.82in (224mm) |
The CLMAL series is a group of premium architectural LED multi-purpose area luminaires designed to illuminate parking lots, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.
FEATURES
▪ Available in 3000k (warm white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
▪ Long-life LEDs provide 372,000 hours of operation with at least 70% of initial lumen output (L70).**
▪ CLMAL-15 provides 1,593 lumens (114 lumens per watt, LPW) at 3000k; 1,603 lumens (115 LPW) at 4000k; and 1,624 lumens (116 LPW) at 5000k.*
▪ Standard optic provides an IES roadway type V distribution, or a 7V (vertical) x 7H (horizontal) NEMA floodlight distribution.
▪ Universal 120-277 AC voltage (50-60Hz) is standard.
▪ Power factor > 0.90.
▪ Total harmonic distortion < 20%.
▪ Color rendering index > 80.
▪ Optional glare shields (full & half) & wire guards are available.
▪ Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heat-resistant polycarbonate lens.
▪ Wireway enclosure is sealed with a water-tight, silicon rubber gasket.
▪ Effective projected areas (EPA's) are:
- Front = 0.05 s.f. (knuckle) / 0.06 s.f. (yoke)
- Side = 0.07 s.f. (knuckle & yoke)
- Face = 0.20 s.f. (knuckle) / 0.23 s.f. (yoke)
▪ Easy installation in new construction or retrofit applications.
* contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.
WARRANTY & LISTINGS
• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F).
• IP66 rated for ingress protection.
• DLC premium approved.
• Rated for 3G vibration.
• Lens is IK 8 rated for protection from external impacts.
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test.
• Complies with FCC Part 15, class B.
• Complies with EN61000-4-5, surge immunity protection (2.5kV).
• 5-Year Warranty of all electronics and housing.
MOUNTING OPTIONS
• Yoke-mounted option provides secure attachment to flat surfaces.
• Aluminum die-cast knuckle-mount option is installed on a junction box. Includes ½” NPS stem with locking nut.
10 Watt Outdoor LED Flood Light, RGB, Color Changing, Energy Efficient. Reduced energy consumption by up to 80%. Remote Control & Power supply included, 2 year guarantee.
| SKU Number | FL-10W-RGB |
| Power Consumption | 10W |
| Traditional Equivalent | 50W |
| Luminous Flux (lm) | 900 Lm |
| Certifications | CE & ROHS |
| IP Rating | IP 65 |
| Material | Aluminum Alloy |
| Plug | No |
| Light Color | RGB |
| Input Voltage | 110-240V AC |
| Beam angle | 120° |
| Lamp Color | Black |
| Length | 4.33in (110.0mm) |
| Height |
3.35in (85mm) |
| Depth |
3.35in (85mm) |
