1 Watt Under Cabinet LED Light, Warm White, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.

4" Gimbal solution with integrated LED power supply and thermal management system combined in a single compact unit designed to fit most standard 4" recessed cans.

ILLUMINATION Long life LEDs with up to 50,000 hours at 70% lumen maintenance. Choice of 2700K, 3000K, 4000K and 5000K color temperature with 80 CRI. Produces 675-750 lumens output from luminaire. Uses 1.18W high power, high quality LEDs.

ELECTRICAL Dimmable to 10% with most dimmers. Save 75% compared to incandescent sources. High efficiency driver with a power factor ≥.90 with input power of 120V, 50-60Hz. Built-in LED Driver. Power consumption of 10 watts. Operation temperature of -20°C - 40°C (-4°F - 104°F).

MOUNTING Easy installation with integral clips. No tools required for installation.

HOUSING Compatible with most 4“ housings. Compatible with insulated, non-insulated, and air-tight ceilings. Durable thermoplastic construction. E26 medium screw-base Edison connector provides easy retrofit of incandescent housings.

WARRANTY/LISTING Tested in accordance with IESNA LM79 & LM80. ETL Listed for wet location. Energy Star qualified. Passes FCC Class B. Meets State of California Title 24 requirements. Five year warranty on all electronics and housing.

Specification Sheet

10 Watt Outdoor LED Flood Light, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.

The CBDEB (dual-ended bypass, which is hot on both ends) series of LED T8 lamps replace conventional fluorescent lamps in existing luminaires. Offering significant energy-efficiency and lifetime improvements over fluorescent lamps, CBDEB lamps are installed by bypassing existing fluorescent ballasts, and hard-wiring tombstone lamp-holders directly to incoming AC power leads. Dual-ended bypass lamps eliminate the need to replace shunted tombstone lamp-holders in existing fluorescent luminaires with instant-start ballasts.

  FEATURES

• Available in 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures (except CBDEB8-43, which is available in 5000k only).*
• Long-life LEDs provide up to 90,000 hours of operation with at least 70% of initial lumens output (L70).**
• Models provide 1,100 to 5,500 lumens per lamp, and 121 to 129 lumens per watt (LPW).*
• Uniform illumination with no visible LED pixilation
• Universal 120-277 AC voltage (50-60Hz) is standard
• Power factor > 0.90.
• Total harmonic distortion < 20%
• Color rendering index ≥ 80.
• Full glass housing inhibits yellowing and distortion
• Easy installation in existing fluorescent luminaires. Bypass models connect directly to incoming AC power leads.

 * contact factory for other color temperatures and lumen packages.

**L70 hours are IES TM-21-11 calculated hours.

  WARRANTY/LISTING

• cULus listed for dry and damp locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F).
• DLC standard approved (except 3- & 8-foot models, which are not eligible under the DLC linear replacement lamps category).
• Complies with RoHS (Restriction on Hazardous Substances) requirements.
• Complies with FCC Part 15 class B.
• CBDEB8-43 has standard PET (polyethylene terephthalate) polyester coating for shatter-proof performance.
• 5-year warranty of all electronics and housing.
• Other models are available as shatter-proof by special order.

Specification Sheet

LEDQuant's M12V-100W-DC is one of the most compact LED drivers on the market with a magnetic transformer core. It is equipped with auto-reset breakers, one on the input and one on the output, which protect both the load and driver. The driver is encased in a coated metal box that includes 2 knock-outs on the bottom to enable easy installation that complies with electrical code requirements.

20 Watt LED Outdoor Flood Light, Cool White, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.

The CLMAL series is a group of premium architectural multi-purpose LED area luminaires designed to illuminate parking areas, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.

FEATURES
• Available in 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 372,000 hours of operation with at least 70% of initial lumen output (L70)**
• Available models provide from 9,816 to 18,408 lumens, and from 117 to 131 lumens per watt (LPW)*
• IES roadway photometric distributions include types II-V
• NEMA floodlight distributions include very narrow (3H x 3V), medium narrow (4H x 4V), medium wide (5H x 5V) & very wide (7H x 7V)
• Universal 120-277 AC voltage (50-60Hz) is standard
• Power factor > 0.90
• Total harmonic distortion < 20%
• Color rendering index > 80
• Optional glare shields (full & half) & wire guards are available
• Optional NEMA photocell installation kit provides watertight photocell attachment to driver enclosure clover
• Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heatresistant polycarbonate lens
• Driver enclosure is sealed with a water-tight, silicone rubber gasket
• Effective projected areas (EPA’s) are:
- Front = 0.24 square feet
- Side = 0.29 square feet
- Face = 1.10 square feet
• Easy installation in new construction or retrofit applications


* Contact factory for other color temperatures and lumen packages.
** L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS

• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F)
• IP66 rated for ingress protection
• DLC premium approved
• Flicker-free per IEEE1789-2015 (no observable adverse effects of flicker at 100% light output level)
• Lens is IK 9 rated for protection from external impacts
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test
• Complies with FCC Part 15, class B
• Complies with EN61000-4-5, surge immunity protection (6kV)
• 5-Year Warranty of all electronics and housing

Specification Sheet

The CLHB-RD-100 is a round LED high bay luminaire, which is designed to illuminate a wide variety of settings, including commercial, industrial & retail settings such as warehouses, manufacturing plants, sporting venues and big-box retailers. With a die cast aluminum housing and polycarbonate lens, the CLHB-RD-100 provides durability and high performance. Highefficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional, HID high bays.

 FEATURES
▪ Available in 4000k (neutral white) and 5000k (cool white) color temperatures.*
▪ Long-life LEDs provide 81,000 hours of operation with at leas t 70% of initial lumen output (L 70).**
▪CLHB-RD-100 provides 13,093 lumens (127 lumens per watt, LPW) at 4000k, and 13,116 lumens (127 LPW) at 5000k.*

▪ Universal 120-277 AC voltage (50-60Hz) is standard. Step down transformers are required for 347-480V applications.
▪ 0-10vdc dimming drivers are standard.
▪ Watertight, compression-type electrical connectors prevent moisture intrusion.
▪ Standard mounting bracket and optional mounting accessories provide ceiling and conduit mounting, and up to 100° of adjustability.
▪ Optional wet-location junction box & bracket attaches to luminaire housing, and simplifies wiring connections in wet locations.
▪ Optional Merrytek occupancy sensor (IP65 rated) and junction box assembly provides a factory-ready, fully-wired luminaire & control package.
▪ Power factor > 0.90.
▪ Total harmonic distortion < 20%.
▪ Color rendering index > 80.
▪ Painted die cast aluminum housing.
▪ Easy installation in new construction or retrofit.

* Contact factory for other color temperatures and lumen packages.
** L 70 hours are IES TM-21-11 calculated hours.

Specification Sheet

Energy efficient LED Flat Square Retrofit kit provides quick and easy installation with no can required. Durable powder-coated diecast trim with enclosed J-box is attached with a water-tight connection. Pre-installed plastic clips included.

 FEATURES
▪ 120V Dimmer standard, 50/60Hz.
▪ Dimmable down to 5% with most market dimmers.
▪ Use for recessed applications with drywall or drop tile ceilings (no recessed can needed).
▪ Small, lightweight J-box standard.
▪ Long life, 50,000 hour LEDs.
▪ -30°C ~ 40°C (-22°F ~ 104°F) operating temperature.

Specification Sheet

120 Watt Corn LED Bulb, High Power, Natual White, Energy Efficient. Retrofit for 400W Metal Halide Lights. Reduced energy consumption by up to 70%. 2 year guarantee.

12V 1A AC/DC Power Adapter for LED Lights, DC Jack, US Plug, UL certified. Great for LED Under Cabinet lights, LED Strips and other LED applications

AC/DC Power Adapter for 5050, 3528 RGB LED Strips, UL certified, 3-Prong US Plug

6” Slope Gimbal solution with integrated LED power supply and thermal management system combined in a single compact unit designed to fit most standard 6” Slope recessed cans.

WARRANTY/LISTING Tested in accordance with IESNA LM79 & LM80. ETL Listed for damp location, US and Canada. Energy Star certified. Passes FCC Class B. Meets State of California Title 24 requirements. Five year warranty on all electronics and housing.

ELECTRICAL Dimmable to 10% with most dimmers. Save 75% compared to incandescent sources. High efficiency driver with a power factor ≥ .90 with input power of 120V, 50-60Hz. Built-in LED Driver Power consumption of 13 watts. Operation temperature of -20°C thru 40°C (-4°F thru 104°F).

ILLUMINATION Long life LEDs with up to 50,000 hours at 70% lumen maintenance. Choice of 2700K, 3500K, and 4000K, color temperatures with 80 CRI. Produces 975 lumens output from luminaire. Uses 1.18W high power, high quality LEDs. HOUSING Compatible with most 6” Slope housings (30° Max. TILT). Compatible with insulated, non-insulated, and slope ceilings. Durable thermoplastic construction E26 medium screw-base Edison connector provides easy retrofit of incandescent housings.

MOUNTING Easy installation with adjustable torsion spring. No tools required for installation. Torsion spring is designed to fit into 6” slope ceiling housing automatically without changing mounting tab.

Specification Sheet

The CLMAL series is a group of premium architectural multi-purpose LED area luminaires designed to illuminate parking areas, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.


 FEATURES
• Available in 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 372,000 hours of operation with at least 70% of initial lumen output (L70)**
• Available models provide from 9,816 to 18,408 lumens, and from 117 to 131 lumens per watt (LPW)*
• IES roadway photometric distributions include types II-V
• NEMA floodlight distributions include very narrow (3H x 3V), medium narrow (4H x 4V), medium wide (5H x 5V) & very wide (7H x 7V)
• Universal 120-277 AC voltage (50-60Hz) is standard
• Power factor > 0.90
• Total harmonic distortion < 20%
• Color rendering index > 80
• Optional glare shields (full & half) & wire guards are available
• Optional NEMA photocell installation kit provides watertight photocell attachment to driver enclosure clover
• Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heatresistant polycarbonate lens
• Driver enclosure is sealed with a water-tight, silicone rubber gasket
• Effective projected areas (EPA’s) are:
- Front = 0.24 square feet
- Side = 0.29 square feet
- Face = 1.10 square feet
• Easy installation in new construction or retrofit applications


* Contact factory for other color temperatures and lumen packages.
** L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS

• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F)
• IP66 rated for ingress protection
• DLC premium approved
• Flicker-free per IEEE1789-2015 (no observable adverse effects of flicker at 100% light output level)
• Lens is IK 9 rated for protection from external impacts
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test
• Complies with FCC Part 15, class B
• Complies with EN61000-4-5, surge immunity protection (6kV)
• 5-Year Warranty of all electronics and housing

Specification Sheet

5” & 6” Gimbal solution with integrated LED power supply and thermal management system combined in a single compact unit designed to fit most standard 5” & 6” recessed cans.

ILLUMINATION Long life LEDs with up to 50,000 hours at 70% lumen maintenance. Choice of 2700K, 3000K or 4000K color temperature with 80 CRI. Produces 975-1050 lumens output from luminaire. Uses 1.18W high power, high quality LEDs.

ELECTRICAL Dimmable to 10% with most dimmers. Save 75% compared to incandescent sources. High efficiency driver with a power factor ≥.90 with input power of 120V, 50-60Hz. Built-in LED Driver. Power consumption of 14 watts. Operation temperature of -20°C - 40°C (-4°F - 104°F).

MOUNTING Easy installation with adjustable torsion spring. Torsion spring is designed to fit into 5” or 6” housing automatically without changing mounting tab. Compatible with most 5” and 6“ housings. Compatible with insulated, non-insulated, and air-tight ceilings. Durable thermoplastic construction. E26 medium screw-base Edison connector provides easy retrofit of incandescent housings.

WARRANTY/LISTING Tested in accordance with IESNA LM79 & LM80. ETL Listed for damp location. Energy Star qualified. Passes FCC Class B. Meets State of California Title 24 requirements. Five year warranty on all electronics and housing.

LEDQuant's M24V-150W-DC is one of the most compact LED drivers on the market with a magnetic transformer core. It is equipped with auto-reset breakers, one on the input and one on the output, which protect both the load and driver. The driver is encased in a coated metal box that includes 2 knock-outs on the bottom to enable easy installation that complies with electrical code requirements.

The CLHB-IB-150 is an LED I-Beam high bay luminaire designed to illuminate commercial, industrial & retail settings such as warehouses, manufacturing plants, sporting venues and big-box retailers. With a painted, steel housing, the CLHB-IB-160 provides durability and high performance. High-efficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional, HIB high bays.

 FEATURES
• Available in 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumen output (L70).**
• Delivers 22,256 lumens from 160 watts input (160 lumens per watt) at both 4000k & 5000k.*
• Universal 120-277 AC voltage (50-60Hz) is standard.
• 0-10vdc dimming capability is standard.
• Power factor > 0.90.
• Total harmonic distortion < 20%.
• Color rendering index > 80.
• Painted steel housing.
• Options include pendant-mounting kits, surface-mounting kits, diffused lenses, and steel wire-guard kits.
• Easy installation in new construction or retrofit.

*Contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY/LISTING
• cETLus listed to applicable U.L. standards. Listed for damp locations. Suitable for ambient temperatures from -20°C to 50°C (-4°F to 122°F).
• DLC premium approved.
• Complies with FCC Part 15, class A.
• Complies with IEEE C.62.41-1991, Class A input transient surge protection (2.5kV).
• Complies with RoHS (Restriction on Hazardous Substances) requirements.
• 5-year warranty of all electronics and housing.

Specification Sheet

The CLHB-RD-150 is a round LED high bay luminaire, which is designed to illuminate a wide variety of settings, including commercial, industrial & retail settings such as warehouses, manufacturing plants, sporting venues and big-box retailers. With a die cast aluminum housing and polycarbonate lens, the CLHB-RD-150 provides durability and high performance. Highefficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional, HID high bays.

 FEATURES
▪ Available in 4000k (neutral white) and 5000k (cool white) color temperatures.*
▪ Long-life LEDs provide 81,000 hours of operation with at leas t 70% of initial lumen output (L 70).**
▪ CLHB-RD-150 provides 18,240 lumens (120 lumens per watt, LPW) at 4000k, and 18,450 lumens (121 LPW) at 5000k.*
▪ Universal 120-277 AC voltage (50-60Hz) is standard. Step down transformers are required for 347-480V applications.
▪ 0-10vdc dimming drivers are standard.
▪ Watertight, compression-type electrical connectors prevent moisture intrusion.
▪ Standard mounting bracket and optional mounting accessories provide ceiling and conduit mounting, and up to 100° of adjustability.
▪ Optional wet-location junction box & bracket (SEE HIGH BAYS ACCESSORIES) attaches to luminaire housing, and simplifies wiring connections in wet locations.
▪ Optional Merrytek occupancy sensor (IP65 rated) and junction box assembly provides a factory-ready, fully-wired luminaire & control package.
▪ Power factor > 0.90.
▪ Total harmonic distortion < 20%.
▪ Color rendering index > 80.
▪ Painted die cast aluminum housing.
▪ Easy installation in new construction or retrofit.

* Contact factory for other color temperatures and lumen packages.
** L 70 hours are IES TM-21-11 calculated hours.

Specification Sheet
