LEDQuant's M24V-40W-DC is one of the most compact LED drivers on the market with a magnetic transformer core. It is equipped with auto-reset breakers, one on the input and one on the output, which protect both the load and driver. The driver is encased in a coated metal box that includes 2 knock-outs on the bottom to enable easy installation that complies with electrical code requirements.

Item: BLD-GM40D-YYY

Output Power: 40W
Output Voltage: 170V DC
Input Power: 15W max
Input Voltage: 100-347Vac, 50/60HZ
Input Current: 200mA max
Application: ≤300W(0-10V Dim Fixture)
 <40W NO 0-10V Dim Fixture
Ambient Temperature: 5 °C to +50 °C （41°F to 122°F)

Package:
Packing size:  16.73x 8.46 x 2.56 inch
Weight: 4.75  LBS (1 PCS )
Packing size: 17.72 x  17.52 x 13.78 inch
Weight:  47.52 LBS ( 10 PCS)

Download:
DATA/SPEC SHEET

Selectable LED Slim Adjustable Wall Pack series can be widely used in indoor or outdoor lighting (wet location). The head tilts from 0º to 90º. Ideal for mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station, indoor stadiums.

** Photocell control available (Standard)**
** 1-10V Dimming**

Power: 40W / 60W / 80W
Input: AC 120-277V
CCT: 3000K/4000K/5000K
Output: 10000LM/11200LM/10800LM
Light Source: Lumileds
Driver: Daermay

Factory Default Parameters:
Power:80W
CCT：4000K

The Architectural WALL PACK LED Lighting Series can be widely used for indoor or outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications


Power: 45W
Input: AC 120-277V
CCT: 5000K
Output: 6741 LM
Light Source: Lumileds
Driver: WELED POWER

Adjustable WALL PACK LED Lighting Series can be widely used for indoor and outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.


Power: 45W
Input: AC 120-277V
CCT：5000K
Output: 5895 Lm
Light Source: Lumileds
Driver: KERHAM

Selectable LED GLASS WALL PACK LED Lighting Series can be widely used for indoor or outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

Power: 48W / 72W / 96W / 120W
Input: AC 120-277V
CCT: 3000K /4000K / 5000K
Output: 6990 LM / 10447 LM
13422 LM / 16767LM

Factory Default Setup:
Power: 120W
CCT: 4000K
Light Source: 2835 LEDs
Driver: KERHAM

Selectable LED Architectural Wall Pack Lighting series can be widely used in indoor or outdoor lighting (wet location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

12Vdc Auxiliary Dimming

Power: 48W / 72W / 96W / 120W
Input: AC 277-480V
CCT: 4000K / 5000K
Output: 7800 LM/11288 LM/14627 LM/18550 LM
Type of lighting： T3 / T4 / T5

Factory Default Parameters:
Power: 120W
CCT：4000K
Type of lighting: T4
Driver: KERHAM

Selectable LED Architectural Wall Pack Lighting series can be widely used in indoor or outdoor lighting (wet location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.

12Vdc Auxiliary Dimming

Power: 48W / 72W / 96W / 120W
Input: AC 120-277V
CCT: 4000K / 5000K
Output: 7800 LM/11288 LM/14627 LM/18550 LM
Type of lighting： T3 / T4 / T5

Factory Default Parameters:
Power: 120W
CCT：4000K
Type of lighting: T4
Driver: KERHAM

The CLLS series is a group of 2’, 3’, 4’ and 8’ covered strip lights, which are designed as direct replacements for fluorescent strips. The CLLS series is designed to deliver general ambient lighting in a variety of indoor settings, including schools, offices, hospitals and stores, and is the perfect choice for both new construction and retrofits. This high-efficacy luminaire provides long-life and uniform illumination, as well as standard 0-10vdc dimming capability.

FEATURES
• Available in 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide up to 122,000 hours of operation with at least 70% of initial lumen output (L70).**
• Uniform illumination with no visible LED pixilation
• Universal 120-277 AC voltage (50-60Hz) is standard
• 0-10vdc dimming capability is standard.
• Power factor > 0.90.
• Total harmonic distortion < 20%
• Color rendering index > 80.
• Steel housing and acrylic lens.
• Easy installation in new construction or retrofit.

 * contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY/LISTING
• cULus approved for damp locations (-20°C to 50°C / -4°F to 122°F).
• DLC premium approved.
• Complies with RoHS (Restriction on Hazardous Substances) requirements.
• Complies with FCC Part 15 class A.
• Complies with IEEE C.62.41-1991, Class A input transient surge protection (2.5kV).
• Complies with IEEE 61000-4-2 level 2 (4kV) electrostatic discharge (ESD).

Specification Sheet

The CLVTL-40 is a surface-mounted LED luminaire, which is designed to prevent the intrusion of moisture and dust. The CLVTL-40 provides general ambient lighting in commercial and industrial settings, and is the perfect choice for both new construction and retrofits. This high-efficacy luminaire provides long-life and uniform illumination, as well as standard 0-10vdc dimming capability.

 FEATURES
• Available in 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumen output (L70).**
• Choose from 4,793 luminaire lumens (120 LPW) at 3500k; 5,200 luminaire lumens (130 LPW) at 4000k; and 5,240 luminaire lumens (131 LPW) at 5000k.*
• Uniform illumination with no visible LED pixelation.
• Universal 120-277 AC voltage (50-60Hz) is standard.
• Power factor > 0.95.
• Total harmonic distortion < 10%.
• Color rendering index > 80.
• ABS (acrylonitrile butadiene styrene) housing and polycarbonate lens
• Stainless steel mounting bracket and lens clips are standard.
• Easy installation in new construction or retrofit.

*Contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY/LISTING
• cULus listed for wet locations (-20°C to 50°C / -4°F to 122°F).
• IP65 rated for ingress protection.
• DLC premium approved.
• Complies with FCC Part 15, class A.
• Complies with IEEE C.62.41-1991, Class A input transient surge protection (2.5kV).
• Complies with IEC 61000-4-2 level 2 (4kV) electrostatic discharge (ESD).
• Complies with RoHS (Restriction on Hazardous Substances) requirements.
• 5-year warranty of all electronics and housing.

Specification Sheet

The CLVTL-52 is a surface-mounted LED luminaire, which is designed to prevent the intrusion of moisture and dust. The CLVTL-52 provides general ambient lighting in commercial and industrial settings, and is the perfect choice for both new construction and retrofits. This high-efficacy luminaire provides long-life and uniform illumination, as well as standard 0-10vdc dimming capability.

 FEATURES
• Available in 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumen output (L70).**
• Provides 5,307 luminaire lumens (100 LPW) at 3500k;
• Uniform illumination with no visible LED pixelation.
• Universal 120-277 AC voltage (50-60Hz) is standard.
• Power factor > 0.95.
• Total harmonic distortion < 10%.
• Color rendering index > 80.
• ABS (acrylonitrile butadiene styrene) housing and polycarbonate lens
• Stainless steel mounting bracket and lens clips are standard.
• Easy installation in new construction or retrofit.

*Contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY/LISTING
• cULus listed for wet locations (-20°C to 50°C / -4°F to 122°F).
• IP65 rated for ingress protection.
• DLC premium approved.
• Complies with FCC Part 15, class A.
• Complies with IEEE C.62.41-1991, Class A input transient surge protection (2.5kV).
• Complies with IEC 61000-4-2 level 2 (4kV) electrostatic discharge (ESD).
• Complies with RoHS (Restriction on Hazardous Substances) requirements.
• 5-year warranty of all electronics and housing.

Specification Sheet

The WRS-5L is a 4’ LED wrap luminaire, which is designed as a direct replacement for fluorescent wraps. It's designed to deliver general ambient lighting in a variety of indoor settings, including schools, offices, hospitals and stores, and is the perfect choice for both new construction and retrofits. This high-efficacy luminaire provides long-life and uniform illumination, as well as standard 0-10vdc dimming capability. It's FCC Part B15 certified.

 FEATURES
• Field selectable 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 196,000 hours of operation with at least 70% of initial lumen output (L70), and 60,000 with at least 90% of initial lumen output**
• WRS-5L provides a range of 4,100 to 5,800 nominal lumens  and 132 to 154 Lumens per watt (LPW) *
• Uniform illumination with no visible LED pixelation.
• Universal 120-277 AC voltage (50-60Hz) is standard.
• 0-10vdc dimming capability is standard.
• Power factor > 0.90.
• Total harmonic distortion < 20%.
• Color rendering index > 80.
• Steel housing and PMMA lens.
• Easy installation in new construction or retrofit.

*Contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY/LISTING
• cULus listed for damp locations (-20°C to 60°C / -4°F to 140°F).
• DLC premium approved.
• Complies with FCC Part 15, class B.
• Complies with IEEE C.62.41-1991, Class A input transient surge protection (2.5kV).
• 5-year warranty of all electronics and housing.

Specification Sheet

The CLWAL-40 is a 1’ x 4’ LED wrap luminaire, which is designed as a direct replacement for fluorescent wraps. The CLWAL-40 is designed to deliver general ambient lighting in a variety of indoor settings, including schools, offices, hospitals and stores, and is the perfect choice for both new construction and retrofits. This high-efficacy luminaire provides long-life and uniform illumination, as well as standard 0-10vdc dimming capability.

 FEATURES
• Available in 3500k (warm/neutral white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumen output (L70).**
• Choose from 4,771 luminaire lumens (119 LPW) at 3500k; 5,200 luminaire lumens (130 LPW) at 4000k; and 5,240 luminaire lumens (131 LPW) at 5000k.*
• Uniform illumination with no visible LED pixelation.
• Universal 120-277 AC voltage (50-60Hz) is standard.
• 0-10vdc dimming capability is standard.
• Power factor > 0.90.
• Total harmonic distortion < 20%.
• Color rendering index > 80.
• Steel housing and acrylic lens.
• Easy installation in new construction or retrofit.

*Contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY/LISTING
• cULus listed for damp locations (-20°C to 50°C / -4°F to 122°F).
• DLC premium approved.
• Complies with FCC Part 15, class A.
• Complies with IEEE C.62.41-1991, Class A input transient surge protection (2.5kV).
• Complies with IEC 61000-4-2 level 2 (4kV) electrostatic discharge (ESD).
• Complies with RoHS (Restriction on Hazardous Substances) requirements.
• 5-year warranty of all electronics and housing.

Specification Sheet

Ideal for replacement of conventional lighting systems such as HID and fluorescent. Applications include manufacturing warehousing and other large indoor spaces with mounting heights from 10ft. to 40ft. the fixture can be surface mounted also.

• High Quality LED Chips to Provide High Efficiency, Heat Dissipation
• Polycarbonate Lens, High Flame Retardant Point
• Operating Temperature: -4°F ~ 131°F

Specification Sheet

The CLHB-LF-178 is a full-body, premium-performance LED high bay luminaire. It is designed to illuminate a wide variety of settings, including commercial, industrial & retail settings such as warehouses, manufacturing plants, sporting venues and big-box retailers. With a painted, steel housing, the CLHB-LF-178 provides durability and high performance. High-efficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional, HID high bays.

The CLHB-LF-265 is a full-body, premium-performance LED high bay luminaire. It is designed to illuminate a wide variety of settings, including commercial, industrial & retail settings such as warehouses, manufacturing plants, sporting venues and big-box retailers. With a painted, steel housing, the CLHB-LF-265 provides durability and high performance. High-efficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional, HID high bays.

The CLHB-LF-320 is a full-body, premium-performance LED high bay luminaire. It is designed to illuminate a wide variety of settings, including commercial, industrial & retail settings such as warehouses, manufacturing plants, sporting venues and big-box retailers. With a painted, steel housing, the CLHB-LF-320 provides high levels of durability and performance. High-efficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional, HID high bays.

 FEATURES

• Available in 4000k (neutral white) and 5000k (cool white) color temperatures.*

• Long-life LEDs provide 122,000 hours of operation with at least 70% of initial lumens output (L70).**

• Delivers 44,298 lumens (138 lumens per watt, LPW) at 4000k, and 44,490 lumens (140 LPW) at 5000k.*

• Universal 120-277 AC voltage (50-60Hz) is standard. Step-down transformers are required for 347-480V applications.

• 0-10vdc dimming drivers are standard.

• Power factor > 0.90.

• Total harmonic distortion < 20%

• Color rendering index > 80.

• Painted steel housing.

• Easy installation in new construction or retrofit.

• Chain-mount kits (includes v-hooks and ⅛“ thick, 1-meter long chain) are standard.

• Options include lenses (clear & diffused), wire-guard kits, surface-mounting kits, pendant-mounting kits, and cable-mounting kits.

* contact factory for other color temperatures and lumen packages.

**L70 hours are IES TM-21-11 calculated hours.

The SSL series (Selectable Strip Light) LED linear light is ideal for replacement of fluorescent lights or new installation. The desired Power (W) and CCT (K) are field selectable which makes this fixture a versatile solution for multiple commercial and industrial applications.  The fixture provides well-distributed illumination. Lifespan: 100,000 hrs. Mounting: Surface and suspended

ELECTRICAL

Power: 25W, 30W, 40W,  (Field Selectable)

CCT: 3500K, 4000K, 5000K (Field Selectable)

Efficacy: 130 lm/W

CRI > 80

Operating voltage: 120-277V AC

Dimming: 0-10V

Power factor > 0.9

OPTICS / FINISH

Beam angle: 112°

Steel housing

Frosted acrylic lens

White finish

WARRANTY

5-years warranty

50 Watt LED Outdoor Flood Light, Cool White, Energy Efficient. Reduced energy consumption by up to 80%. 2 year guarantee.

LED GLASS WALL PACK Lighting series can be widely used as indoor or outdoor lighting (Wet location). Perfect for mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station, indoor stadiums and flower cultivating tents, etc.


Power: 50W
Input: AC 120-277V
CCT：5000K
Output: 6600 LM
Light Source: Lumileds
Driver: WELED POWER

The CLMAL series is a group of premium architectural multi-purpose LED area luminaires designed to illuminate parking areas, pathways, building facades, loading docks, and a wide variety of other large, general site lighting applications. Multiple mounting options make the CLMAL a versatile luminaire for flood lighting, pole-, ground- and wall-mounted are lighting, and other outdoor lighting requirements.

 FEATURES

• Available in 3000k (warm white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Long-life LEDs provide 230,000 hours of operation with at least 70% of initial lumen output (L70).**
• CLMAL-50 provides 5,717 lumens (117 lumens per watt, LPW) at 3000k; 5,778 lumens (118 LPW) at 4000k; and 5,793
lumens (118 LPW) at 5000k.*
• Standard optic provides an IES roadway type V distribution, or a 7V (vertical) x 7H (horizontal) NEMA floodlight distribution.
• Universal 120-277 AC voltage (50-60Hz) is standard.
• Power factor > 0.90.
• Total harmonic distortion < 20%.
• Color rendering index > 80.
• Optional glare shields (full & half) & wire guards are available.
• Die cast aluminum housing with durable, dark bronze powder coat finish—at least 2 mils thick on all surfaces—and a heat-resistant polycarbonate lens.
• Wireway enclosure is sealed with a water-tight, silicon rubber gasket.
• Effective projected areas (EPA’s) are:
- Front = 0.15 s.f. (knuckle) / 0.13 s.f. (yoke)
- Side = 0.18 s.f. (knuckle) / 0.13 s.f. (yoke)
- Face = 0.73 s.f. (knuckle) / 0.57 s.f. (yoke)
• Easy installation in new construction or retrofit applications.

* contact factory for other color temperatures and lumen packages.
**L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS

• cULus listed for wet locations in ambient temperatures from -20°C to 45°C (-4°F to 113°F).
• IP66 rated for ingress protection.
• DLC premium approved.
• Rated for 3G vibration.
• Lens is IK 8 rated for protection from external impacts.
• Salt fog tested for 1,000 hours (ASTM B117). After salt fog testing, paint rated at 9 per ASTM D1654-05 scratch test.
• Complies with FCC Part 15, class B.
• Complies with EN61000-4-5, surge immunity protection (2kV).
• 5-year warranty of all electronics and housing

 MOUNTING OPTIONS

• Yoke-mounted option provides secure attachment to flat surfaces.
• Aluminum die-cast knuckle-mount option is installed on a junction box. Includes ½” NPS stem with locking nut.

Specification Sheet

The CLADL series is a 6” commercial grade architectural downlight (includes can & frame-in kit). Built for commercial use with architectural frames and a deep cone reflector for precision light. This high-efficiency luminaire provides long life and minimal need for maintenance. UL and Energy Star listed.

 FEATURES
• Architectural frames
• C channel and flat hanger bars for tie down to ceiling grids
• Junction box is mounted on the frame for easy wiring,driver access for installation, and replacement
• Diecast aluminum heatsink dissipates heat from the LED board
• Self-flanged aluminum reflector with a frosted lens to shield direct view of LEDs
• Color rendering index ≥ 80
• Long life LEDs - up to 50,000 hours
• Universal 120-277 AC voltage (50/60Hz)
• 0-10V dimming
• Operation Temp. -30°C~40°C (-22°F~104°F)

* Contact factory for other color temperatures and lumen packages.
** L70 hours are IES TM-21-11 calculated hours.

 WARRANTY & LISTINGS
• cULus Listed.
• ENERGY STAR® rated.
• Suitable for wet locations (not suitable for coastal/saltwater areas).
• Suitable for damp locations.
• RoHS compliant.
• 5-year warranty of all electronics and housing.

Specification Sheet

LEDQuant's M12V-60W-DC is one of the most compact LED drivers on the market with a magnetic transformer core. It is equipped with auto-reset breakers, one on the input and one on the output, which protect both the load and driver. The driver is encased in a coated metal box that includes 2 knock-outs on the bottom to enable easy installation that complies with electrical code requirements.

The Architectural WALL PACK LED Lighting Series can be widely used for indoor or outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications


Power: 70W
Input: AC 120-277V
CCT：5000K
Output: 9841 LM
Light Source: Lumileds

Adjustable WALL PACK LED Lighting Series can be widely used for indoor or outdoor lighting (Wet Location). Excellent for museums, art galleries, shopping malls, office buildings, walls and many other applications.


Power: 70W
Input: AC 120-277V
CCT: 5000K
Output: 9170 Lm
Light Source: Lumileds
Driver: KERHAM

LED GLASS WALL PACK Lighting series can be widely used as indoor or outdoor lighting (Wet location). Perfect for mechanical or electronic processing workshops, storage warehouses, steel mills, gas stations, toll booth, waiting rooms, the platforms of railway station, indoor stadiums and flower cultivating tents, etc.


Power: 70W
Input: AC 120-277V
CCT：5000K
Output: 9380 LM
Light Source: Lumileds
Driver: WELED POWER

7W Dimmable LED Recessed Light w/Cable & Plug, 3500K CCT

7W LED Recessed Light w/Cable & Plug, Cool White 6000K
