EMERGENCY
-
Visit product page →Item：WSD-LHB-TBAR-G2
Download：
DATA /SPEC SHEETPackage:
Packing size: 14x3x1 inch
Weight： 0.4 LBS 1 PCS） -
Visit product page →Item：WSD-TBAR Mounting Kit
Download:
DATA/SPEC SHEET -
LEDQuant
Compact LED Exit Sign, Emergency Light, Double Face, Green Letter, Battery Backup, UL
$18.99
vLEDQuant
Compact LED Exit Sign, Emergency Light, Double Face, Green Letter, Battery Backup, UL
$18.99
Visit product page →• Ultra-compact, low-profile design
• Easy to install, snap together design
• Rugged, injection-molded UL94 V-0 flame retardant, high-
temperature thermoplastic housing
• Universal style - includes 2 face plates, a back plate and mounting
canopy
• Brown-out, short circuit and voltage surge protection
• Overcharge protection
• Maintenance-free NiCad battery
• Universal J-Box mounting system - Ceiling, wall or end mount
• ETL listed 90 minute emergency run time, 24 hour recharge time
• Constant, uniform illumination by long-life, high intensity, red or
green LEDs
• Fully-illuminated 6” characters with 3/4” stroke
• Chevron-style, universal arrow knockouts
• 120/277V dual primary, 60Hz input
• Standard finishes: Black or white
• Suitable for damp location -
Visit product page →2W LED 2-HEAD EMERGENCY UNIT
ILLUMINATION• Long lasting, efficient, ultra bright white LED lamp heads.• 1W (8 LEDs x 0.125) per head.• High performance chrome-plated metallized reflector and plastic lens for optimal light distribution.• Adjustable LED lamp heads provides optimal center-to-center spacing. High-lumen option available for increased center-to-center spacing.ELECTRICAL• Dual 120/277 voltage standard. Optional multi-tap 208/220/240 voltage available.• Remote capacity standard.• Charge rate/power “ON” LED indicator light and push to test switch for mandated code compliance testing.• 3.6V Long-life, maintenance-free, rechargeable NiCd battery.• Internal solid-state transfer switch automatically connects the internal battery to LED lamp heads for minimum 90-minute emergency illumination.• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.WARRANTY / LISTING• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.• UL listed for damp locations. (0°C - 50°C).• Five year warranty of all electronics and housing. Battery pro-rated for five years.OPTIONS• HL: 12-LED per head provide increased center-to-center spacing.• SDT: Self-diagnostic test feature performs monthly, biannually, and annually tests to ensure reliable operation and to meet electrical and life safety codes.• SPV: UL Listed for special voltage option.MOUNTING• Surface mount via easy connect back plate, which fits most standard junction boxes and snaps into place making internal electrical connections.• Top and side knockout for conduit applications.• Suitable for wall or ceiling mount.HOUSING• Injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish. -
Visit product page →ILLUMINATION• Ultra bright, energy efficient, long life Red or Green LED.MOUNTING• Mounting canopy included for top or end mount.• Universal K/O pattern on back plate for wall mount.ELECTRICAL• Dual 120/277 voltage standard.• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.• 1.2V long life, maintenance-free, rechargeable NiCd battery.• Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.HOUSING• Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.• Specification-grade, low profile thin plastic design.• EZ snap-out chevron directional indicators.• Available specifically in single or double face only.WARRANTY/LISTING• Five year warranty on all electronics and housing. Battery prorated for five years.• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.• UL Listed for damp locations (0°C - 50°C). -
Visit product page →ILLUMINATION• Ultra bright, energy efficient, long life Red or Green LED.MOUNTING• Mounting canopy included for top or end mount.• Universal K/O pattern on back plate for wall mount.ELECTRICAL• Dual 120/277 voltage standard.• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.• 1.2V long life, maintenance-free, rechargeable NiCd battery.• Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.HOUSING• Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.• Specification-grade, low profile thin plastic design.• EZ snap-out chevron directional indicators.• Available specifically in single or double face only.WARRANTY/LISTING• Five year warranty on all electronics and housing. Battery prorated for five years.• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.• UL Listed for damp locations (0°C - 50°C). -
Visit product page →Item:BLD-AP24095-EC
Download:
DATA/SPEC SHEET -
vLEDQuant
Compact LED Exit Sign, Emergency Light, Double Face, Red Letter, Battery Backup, UL
$32.49
Visit product page →ILLUMINATION• Ultra bright, energy efficient, long life Red or Green LED.MOUNTING• EZ-snap mounting canopy included for top or end mount.• Universal K/O pattern on back plate for wall mount.ELECTRICAL• Dual 120/277 voltage.• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.• 1.2V long life, maintenance-free, rechargeable NiCd battery.• Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.HOUSING• Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.• Aesthetically pleasing, curved face, rounded corner design.• EZ snap-out chevron directional indicators.WARRANTY/LISTING• Five year warranty on all electronics and housing. Battery pro rated for five years.• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.• UL Listed for damp locations (0°C - 50°C). -
Visit product page →ILLUMINATION• Ultra bright, energy efficient, long life Red or Green LED.ELECTRICAL• Dual 120/277 voltage.• Charge rate/power “ON” LED indicator light and push to test switch for mandated code compliance testing.• 4.8V Long-life, maintenance-free, rechargeable NiCd battery.• Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.WARRANTY / LISTING• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.• UL listed for damp locations. (0°C - 50°C).• Five year warranty of all electronics and housing. Battery pro-rated for five years.OPTIONS• 2C: Dual circuit option on the AC-only unit enables it to be connected to two different (one acting as a back-up to the other) supplies at the same time.• SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes.• Custom: Signs available with requested ‘special’ wording.• USA: Substantial transformation assembly in the U.S. complies with “Assembled in the USA” under the Buy American Act.• cUL: Units tested to meet requirements of CAN/CSA-c22.2 No. 141-02 standard for unit equipment.HOUSING• Injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.• EZ snap-out chevron directional indicators.• Compact, low-profile design.MOUNTING• EZ-snap mounting canopy included for top or end mount.• Universal K/O pattern on back plate for wall mount. -
Visit product page →ILLUMINATION• Ultra bright, energy efficient, long life Red or Green LED.ELECTRICAL• Dual 120/277 voltage.• Charge rate/power “ON” LED indicator light and push to test switch for mandated code compliance testing.• 4.8V Long-life, maintenance-free, rechargeable NiCd battery.• Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.WARRANTY / LISTING• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.• UL listed for damp locations. (0°C - 50°C).• Five year warranty of all electronics and housing. Battery pro-rated for five years.OPTIONS• 2C: Dual circuit option on the AC-only unit enables it to be connected to two different (one acting as a back-up to the other) supplies at the same time.• SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes.• Custom: Signs available with requested ‘special’ wording.• USA: Substantial transformation assembly in the U.S. complies with “Assembled in the USA” under the Buy American Act.• cUL: Units tested to meet requirements of CAN/CSA-c22.2 No. 141-02 standard for unit equipment.HOUSING• Injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.• EZ snap-out chevron directional indicators.• Compact, low-profile design.MOUNTING• EZ-snap mounting canopy included for top or end mount.• Universal K/O pattern on back plate for wall mount. -
Visit product page →HOUSING• Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finishes.• EZ snap-out chevron directional indicators.OPTIONS• SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes.WARRANTY/LISTING• Five year warranty on all electronics and housing. Battery pro rated for five years.• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.• UL Listed for damp locations (0°C – 50°C).ILLUMINATION• Ultra bright, energy efficient white LED emergency lighting.• 4.5W (36 LEDs x 0.125 watts) per light pipe.• Adjustable high performance, smooth, chrome-plated, metallized reflector and acrylic, UV-stabilized “Light Pipe” lens for optimal light distribution.• Long life, energy efficient Red or Green LED EXIT sign illumination.ELECTRICAL• Dual 120/277 voltage.• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.• 4.8V long life, maintenance-free, rechargeable NiCd battery.• Internal solid-state transfer switch automatically connects the internal battery to LED board and LED Light Pipe for minimum 90-minute emergency illumination.• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.• Remote capable standard.MOUNTING• EZ-snap mounting canopy included for top or end mount.• Universal K/O pattern on back plate for wall mount. -
Visit product page →HOUSING• Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finishes.• EZ snap-out chevron directional indicators.OPTIONS• SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes.WARRANTY/LISTING• Five year warranty on all electronics and housing. Battery pro rated for five years.• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.• UL Listed for damp locations (0°C – 50°C).ILLUMINATION• Ultra bright, energy efficient white LED emergency lighting.• 4.5W (36 LEDs x 0.125 watts) per light pipe.• Adjustable high performance, smooth, chrome-plated, metallized reflector and acrylic, UV-stabilized “Light Pipe” lens for optimal light distribution.• Long life, energy efficient Red or Green LED EXIT sign illumination.ELECTRICAL• Dual 120/277 voltage.• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.• 4.8V long life, maintenance-free, rechargeable NiCd battery.• Internal solid-state transfer switch automatically connects the internal battery to LED board and LED Light Pipe for minimum 90-minute emergency illumination.• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.• Remote capable standard.MOUNTING• EZ-snap mounting canopy included for top or end mount.• Universal K/O pattern on back plate for wall mount. -
Item: WSD-EMPK04E27-4WVisit product page →
Output Power: 4 W
Universal Input Voltage:100-277 Vac,50/60 Hz
AC Input Current :100 mA max.
AC Input Power Rating : 5.0 W max.
Output Current and Voltage:30-400 mA
10-60 Vdc
Full Warranty :5 Years
Test Switch Indicator Light: Illuminated Test Switch, indicator Light
Battery: Li-ion battery-3.7 V / 2500 mAh
Battery Charging Current:300 mA max.
Charging Time ≥24 Hours
Temperature Rating (Ambient) :Li-ion 0°C to +50°C (32°F to 120°F)
Package：
Packing size: 6.93 x 2.36 x 1.38 inch
Weight: 0.47 LBS (1 PCS )
Packing size: 15.43 x 12.4 x 8.27 inch
Weight: 23.65LBS (50 PCS)
Download:
DATA/SPEC SHEET -
Visit product page →Item:WSD-PNP20H27
Package：
Package size: 13.35 x 7.28 x 2.36 inch
Weight: 3.17 LBS ( 1PCS)
Package size: 13.98 x 12.8x 8.07 inch
Weight: 15.84 LBS ( 5 PCS)
Download:
DATA/SPEC SHEET -
Visit product page →Item: WSD-300YM08W-AC
Output Power: 8 W
Universal Input Voltage: 100-347Vac,50/60Hz
AC Input Current: 100 mA max.
AC Input Power Rating: 8.0 W max.
Output Voltage: 60-300Vdc
Full Warranty: 5 Years
Test Switch Indicator Light: 2-in 1 test switch and charge indicator light.
Battery: LiFePO4 battery
Battery Charging Current: ≤350mA max.
Charging Time ≥24 Hours
Temperature Rating (Ambient) : 5°C to 60°C (41°F to 140°F)
Package：
Packing size: 9 x 5 x 2 inch
Weight: 2 LBS (1 PCS )
Packing size: 19 x 9 x 10 inch
Weight: 28 LBS (20 PCS)
Download:
DATA/SPEC SHEET -
Item: YH11B-05WL-55Visit product page →
Rated Input Voltage：100-277V 50/60HZ
Input Current: 10-50mA
Input Power: < 4W
Power Factor: >0.50
Output wire L-out N-out (LED Load input): AC1.5A Max
Output Voltage Range: DC25-52V 57V Max
Output Power (Emergency Mode): 5W max
Recharge Current: 0-250mA
Discharge Time: 90 Minutes
Recharge Time: 24Hours
Service Life : 50000 Hours
Max casing temperature tc: 70°C
Package：
Packing size：14.37x12.59 x6.1inch
Weight: 11.46 LBS (18 PCS)
Packing size: 14x11x8 inch
Weight：25.96 LBS (40 PCS）
Download：
DATA/SPEC SHEET -
Visit product page →Item:WSD-EMS8W27-XX
Output Power: 8W
Universal Input Voltage: 100-347Vac,50/60Hz
AC Input Current: 100mA max.
AC Input Power Rating: 7.0W max.
Output Voltage: 36-60Vdc
Emergency Time ≥1.5H
Full Warranty: 5 Years
Test Switch Indicator Light Illuminated Test Switch, indicator Light
Battery: Li-ion baSplit Built-In Emergency Backup Battery ttery-7.2V/2500mAh
Battery Charging Current :250 mA
Charging Time ≥24Hours
Temperature Rating (Ambient): Li-ion 0°C to 40°C (32°F to 104°F)
Package：
Packing size:8.26x3.14x1.57 inch
Weight: 1.8 LBS (0.82kg)
Package size: 13.58 x 8.66 x 8.07 inch
Weight: 36 LBS ( 20 PCS)
Download:
DATA/SPEC SHEET -
LEDQuant
15W Emergency Backup Battery LED Driver For Back-Lit LED Panel Light WSD-EMLY15W27-XX
$104.50
vLEDQuant
15W Emergency Backup Battery LED Driver For Back-Lit LED Panel Light WSD-EMLY15W27-XX
$0.00 $104.50
Item: WSD-EMLY15W27-XXVisit product page →
Application: Back-Lit Panel
Input Voltage: 100-347V AC 50/60HZ
AC Input Current: 100mA max
AC Input Power Rating: 7.0W max
Output Voltage: 30V-60V
Output Power: 15W max
Illumination Time: 90 Minutes
Battery Charging Current: ≤ 250mA
Recharge Time: ≥24Hours
Temperature Rating Ambient: 0°C to + 50°C (32°FF to 122°F)
Package：
Packing Size: 22.83x14.37x9.06 inch
Weight: 22.7 LBS (10PCS)
Download:
DATA/SPEC SHEET -
Visit product page →Item:WSD-170YT08W-AC
Input Voltage:100~347Vac,50/60Hz
Input Current: 100mA max
Input Power: 6W max
Output Voltage: 170V DC
Emergency Power: 8W
Recharge Time: 24Hrs
Discharge Time: 90 minutes
Battery: Li-ion Battery
Ambient Temp: 5°C-50°C(41°F to 122°F)
Download:
DATA/SPEC SHEET -
Visit product page →The Emergency LED driver must connect to 0/1-10V dimming wires (DIM+,DIM-) of the fixture if the LED luminaire power is exceed the emergency LED driver power. (2 In emergency mode, double-click this test switch to turn off the current emergency state.
Item: WSD-EML08W27-XX
Output Power: 8W
Output Voltage: 170V DC
Input Power: 12W max
Input Voltage: 100-347Vac, 50/60HZ
Input Current: 0.1A max
Application: ≤80W (0-10V Dimmable Fixture)
≤8W LED Lamps without dimming function
Ambient Temperature: 5 C~50 C
Package:
Packing size: 17.71 x 6.69 x 1.97 inch
Weight: 2.2 LBS (1 PCS )
Packing size: 18.11 x 13.78 x 9.84 inch
Weight: 22.05 LBS (10 PCS)
Download:
DATA/SPEC SHEET -
LEDQuant
20-50V LED Emergency Backup Driver With Test Button, 90 Minutes, Constant Power, 120-277V Input Voltage, UL Listed
$108.99
vLEDQuant
$108.99
Visit product page →Provides constant power output to the load during emergency mode operation. Designed to be operated as NORMALLY-ON, NORMALLY-OFF or SWITCHED-LOAD. Suitable for installation inside, on-top, or in remote mount of the fixture.
FEATURES
• UL Classified for factory or field installation
• LED illuminated and remote mounted test switch
• Output short/overcurrent protection
• Electronic limiting with normal operation resuming upon removal of fault
• Input overcurrent protection
• Surge protection
• UL Listed for damp locations
• 5 year warranty on all electronics and housings -
Item：BLD-TM04N-050Visit product page →
Output Power:4W
Universal Input Voltage: 100-277Vac,50/60Hz
AC Input Current: 80mA max.
AC Input Power Rating: 5.0W max.
Output Current and Voltage: 80-133mA 30-50Vdc
Emergency Time 1.5H
Full Warranty: 5 Years
Test Switch Indicator Light Illuminated Test Switch, indicator Light
Battery: Li-ion baSplit Built-In Emergency Backup Battery ttery-7.2V/2900mAh
Battery Charging Current :250 mA
Charging Time 24Hours
Temperature Rating (Ambient): -20°C to 55°C (-4°F to 131°F)
Package：
Packing size: 8.07×3.11×1.38 inch
Weight: 0.5 LBS (1PCS)
Package size: 13.58×8.66× 8.07inch
Weight: 9.9LBS （20 PCS)
Download:
DATA/SPEC SHEET -
Item: WSD-EMS15W27-XXVisit product page →
Output Power: 15W
Universal Input Voltage: 100-347Vac,50/60Hz
AC Input Current: 100mA max.
AC Input Power Rating: 7.0W max.
Output Voltage: 36-150Vdc
Emergency Time ≥1.5H
Full Warranty: 5 Years
Test Switch Indicator Light Illuminated Test Switch, indicator Light
Battery Charging Current :≤350 mA
Charging Time: 24 Hours
Temperature Rating (Ambient): Li-ion 0°C to 50°C (32°F to 122°F)
Package：
Package size: 13.58 x 8.66 x 8.07 inch
Weight: 20.94 LBS ( 20 PCS)
Download:
DATA/SPEC SHEET -
LEDQuant
8W Low Temperature Split Built-In Emergency Backup Battery Driver 100-347Vac WSD-EMS08W27-LT2
$129.80
vLEDQuant
8W Low Temperature Split Built-In Emergency Backup Battery Driver 100-347Vac WSD-EMS08W27-LT2
$129.80
Visit product page →Item：WSD-EMS08W27-LT2
Output Power: 8W
Universal Input Voltage: 100-347Vac,50/60Hz
AC Input Current: 100mA max.
AC Input Power Rating: 7.0W max.
Output Current and Voltage: 133-222mA 36-60Vdc
Emergency Time 1.5H
Full Warranty: 5 Years
Test Switch Indicator Light Illuminated Test Switch, indicator Light
Battery: Cold Rated Li-ion Battery
Battery Charging Current :250 mA
Charging Time 24Hours
Temperature Rating (Ambient): -20°C to 60°C (-4°F to 140°F)
Package：
Packing size: 8.23x4.33x1.57 inch
Weight: 0.97 LBS (1 PCS)
Package size: 18.11 x 8.86 x 9.06 inch
Weight: 19.43 LBS ( 20 PCS)
Download:
DATA/SPEC SHEET -
vLEDQuant
9-15W Adjustable Watts and CCT Emergency Battery Back up WSD-EMT91215W12-5CCT
$0.00 $129.80
Visit product page →Item: WSD-EMT91215W12-5CCT
Output Power: 4.2 W
Universal Input Voltage: AC120V,50/60Hz
AC Input Current: 200mA max
AC Input Power Rating: 21W max
Output Voltage: DC30-36V
Full Warranty: 5 Years
Battery: Li-ion battery
Battery Charging Current: ≤390mA
Charging Time: ≥24 Hours
Temperature Rating (Ambient): 5°C to 50°C (41°F to 122°F)
Package：
Packing size: 10 x 5 x 2 inch
Weight: 2 LBS (1 PCS )
Packing size: 20 x 10 x 10 inch
Weight: 28 LBS (20 PCS)
Download:
DATA/SPEC SHEET -
Item: WSD-EMS20W27-XXVisit product page →
Output Power: 20W
Universal Input Voltage: 100-347Vac,50/60Hz
AC Input Current: 100mA max.
AC Input Power Rating: 7.0W max.
Output Voltage: 36-150Vdc
Emergency Time ≥1.5H
Full Warranty: 5 Years
Test Switch Indicator Light Illuminated Test Switch, indicator Light
Battery Charging Current :≤350 mA
Charging Time: 24 Hours
Temperature Rating (Ambient): Li-ion 0°C to 50°C (32°F to 122°F)
Package：
Package size: 13.58 x 8.66 x 8.07 inch
Weight: 21.38 LBS ( 20 PCS)
Download:
DATA/SPEC SHEET -
Visit product page →The Emergency LED driver must connect to 0/1-10V dimming wires (DIM+,DIM-) of the fixture if the LED luminaire power is exceed the emergency LED driver power. (2 In emergency mode, double-click this test switch to turn off the current emergency state.
Item: WSD-EML15W27-XX
Output Power: 15W
Output Voltage: 170V DC
Input Power: 12W max
Input Voltage: 100-347Vac, 50/60HZ
Input Current: 0.1A max
Application: ≤150W (0-10V Dimmable Fixture)
≤15W LED Lamps without dimming function
Ambient Temperature: 5 C~50 C
Package:
Packing size: 17.71 x 6.69 x 1.97 inch
Weight: 2.29 LBS (1 PCS )
Packing size: 18.11 x 13.78 x 9.84 inch
Weight: 24.47 LBS (10 PCS)
Download:
DATA/SPEC SHEET -
Visit product page →Item: WSD-300YM25W-AC
Output Power: 25 W
Universal Input Voltage: 100-347Vac,50/60Hz
AC Input Current: 100 mA max.
AC Input Power Rating: 25 W max.
Output Voltage: 60-300Vdc
Full Warranty: 5 Years
Test Switch Indicator Light: 2-in 1 test switch and charge indicator light.
Battery: LiFePO4 battery
Battery Charging Current: ≤350mA max.
Charging Time ≥24 Hours
Temperature Rating (Ambient) : 5°C to 60°C (41°F to 140°F)
Package：
Packing size: 10 x 5 x 2 inch
Weight: 2 LBS (1 PCS )
Packing size: 20 x 10 x 10 inch
Weight: 28 LBS (20 PCS)
Download:
DATA/SPEC SHEET -
Visit product page →The Emergency LED driver must connect to 0/1-10V dimming wires (DIM+,DIM-) of the fixture if the LED luminaire power is exceed the emergency LED driver power. (2 In emergency mode, double-click this test switch to turn off the current emergency state.
Item: WSD-EML20W27-XX
Output Power: 20W
Output Voltage: 170V DC
Input Power: 12W max
Input Voltage: 100-347Vac, 50/60HZ
Input Current: 0.1A max
Application: ≤150W(0-10V Dimmable Fixture)
≤20W LED Lamps without dimming function
Ambient Temperature: 5 C~50 C
Package:
Packing size: 17.71 x 6.69 x 1.97 inch
Weight: 2.29 LBS (1 PCS )
Packing size: 18.11 x 13.78 x 9.84 inch
Weight: 24.47 LBS (10 PCS)
Download:
DATA/SPEC SHEET -
Item: YH29FA-16VNVisit product page →
Rated Input Voltage：100-277VAC 50/60HZ
Input Current: 120mA Max
Input Power: 8W max
Power Factor: 0.6@100VAC 0.5@347VAC
Output wire L-out N-out (LED Load input): AC 6A Max
Output Voltage Range: DC150-200V
MAX Output Voltage: 250V
Recharge Current: 0-500mA
Discharge Time: 90 Minutes
Recharge Time: 24 Hours
Service Life: 50000 Hours
Max casing temperature tc: 70°C
Package：
Packing size：17.12x14.17 x10.24 inch
Weight: 23.15 LBS (5 PCS)
Download：
DATA/SPEC SHEET -
LEDQuant
15W Low Temperature Split Built-In Emergency Backup Battery Driver 100-347Vac WSD-EMS15W27-LT20
$160.60
vLEDQuant
15W Low Temperature Split Built-In Emergency Backup Battery Driver 100-347Vac WSD-EMS15W27-LT20
$160.60
Visit product page →Item: WSD-EMS15W27-LT20
Output Power: 15W
Universal Input Voltage: 100-347Vac,50/60Hz
AC Input Current: 100mA max.
AC Input Power Rating: 7.0W max.
Output Current and Voltage: 100-416mA 36-150Vdc
Emergency Time 1.5H
Full Warranty: 5 Years
Test Switch Indicator Light Illuminated Test Switch, indicator Light
Battery: Cold Rated Li-ion Battery
Battery Charging Current: 250 mA
Charging Time 24Hours
Temperature Rating (Ambient): -20°C to 60°C (-4°F to 140°F)
Package：
Packing size: 8.07x3.11x1.38 inch
Weight: 2.62 LBS (1PCS)
Package size: 13.58 x8.66x8.07 inch
Weight: 52.32 LBS (20PCS)
Download:
DATA/SPEC SHEET -
Item: YH29FA-25VLVisit product page →
Rated Input Voltage:100-277VAC 50/60HZ
Input Current: 120mA Max
Input Power: 8W max
Power Factor: 0.6@100VAC
Output wire L-out N-out (LED Load input): AC 6A Max
Output Voltage Range: DC150-200V
MAX Output Voltage: 250V
Recharge Current: 0-500mA
Discharge Time: 90 Minutes
Recharge Time: 24 Hours
Service Life: 50000 Hours
Max casing temperature tc: 70°C
Package：
Packing size：17.12x14.17 x10.24 inch
Weight: 23.15 LBS (5 PCS)
Download：
DATA/SPEC SHEET -
10W Emergency LED DriverVisit product page →
Item：BSL10T3UAK55PKI2
Universal Input Voltage：120-277 VAC, 50/60 Hz
Output Voltage：15 - 54 VDC
ABConnect Equipped
Self-Test Selectable
Metal IP65 Test Switch/Indicator Light
Illumination Time：90 Minutes
12 NC number: 913702492801
Package：
14.1” x 1.18” x 1.0” (358 mm x 30 mm x 25 mm)
Mounting Center 13.78” (350 mm)
Weight： 0.95 lbs. (0.44 kg)
Download：
DATA/SPEC SHEET -
Visit product page →Item: BLD-GM40D-YYY
Output Power: 40W
Output Voltage: 170V DC
Input Power: 15W max
Input Voltage: 100-347Vac, 50/60HZ
Input Current: 200mA max
Application: ≤300W(0-10V Dim Fixture)
<40W NO 0-10V Dim Fixture
Ambient Temperature: 5 °C to +50 °C （41°F to 122°F)
Package:
Packing size: 16.73x 8.46 x 2.56 inch
Weight: 4.75 LBS (1 PCS )
Packing size: 17.72 x 17.52 x 13.78 inch
Weight: 47.52 LBS ( 10 PCS)
Download:
DATA/SPEC SHEET -
The Wisdom UFO8D/R Series LED emergency drivers are designed for use with UFO LED high bay fixtures with 0-10V dimmable LED drivers. It allows the LED UFO High Bay to be used for both normal and emergency operation.Visit product page →
Item: LECV-UFO30D
Power: 30W
Input Voltage: 100-347VAC 50/60Hz
Output Voltage: 120-180 Vdc
Emergency Time: 90 Min
Full Warranty: 5 Years
Ambient Temp: 0°C to 50°C (32°F to 122°F)
Package：
Packing size: 13.39x10.24x6.1 inch
Weight：8.27 LBS (1 PCS）
Packing size: 18x17x7 inch
Weight：15.62 LBS (2 PCS）
Download:
DATA/SPEC SHEET -
Visit product page →Item：WSD-IPEM480V-30W
SKU :201.0428
Input Voltage :277-480V AC, 50/60Hz
Output Voltage :400V DC
Input Current:100mA max.
Output Current:200mA max.
Output Power:30W
Emergency Time;90 minutes
Charging Time:≥24 hours
Battery Type:Lithium ion
Ambient Temp:0℃~50℃
Package：
Packing size: 20.28 x 17.13 x 13.58 inch
Weight:52.58 LBS (10 PCS)
Download：
DATA/SPEC SHEET -
Item: YH27FA-40WLVisit product page →
Rated Input Voltage: 100-347VAC 50/60HZ
Input Current: 150mA
Input Power： 8.5W max
Power Factor： 0.6@100VAC 0.5@347VAC
Output wire L-out N-out (LED Load input): AC 6A Max
Output Voltage Range: DC150-200V
MAX Output Voltage: 250V
Recharge Current: 0-500mA
Discharge Time: 90 Minutes
Recharge Time: 24 Hours
Service Life: 50000 Hours
Max casing temperature tc: 69.1°C
Package：
Package Size: 19.65x14.37x12.83 inch
Weight: 13.89 (2 pcs)
Download：
DATA/SPEC SHEET -
Visit product page →**Remote Control Standard**
Item: WSD-EMUFO40W347-R
Power: 40W
Input Voltage: 100-347VAC 50/60H
Output Voltage: 170 Vdc
Input Power:15 W
Input Current:≤200 mA
Battery : Li-ion Battery
Charging Time ≥24Hours
Emergency Time: 90 Min
Full Warranty: 5 Years
Ambient Temp: 5°C to 50°C
Package：
Package size: 23.62 x 16.34 x 9.25 inch
Weight: 30.75 LBS ( 4 PCS)
Download:
DATA/SPEC SHEET
